12 k1evo706en-2011-07 Kaba Terminal 9420 MID
Product description User manual
3.8 Technical specifications
Dimensions
W x H x D 264 x 207 x 96 mm
Material
Housing Black high-gloss plastic
Display Monochrome graphic display
Resolution: 320 x 240 pixels (QVGA)
Backlighting with white LED
Keypad Capacitive keypad dependent on software
licence
Power supply
Mains voltage 100 - 240 V AC
Frequency: 50 - 60 Hz
Power consumption: max. 200 mA
Operating environments
Protection class IP54 (bottom cable entry using enclosed
grommets)
Temperature -10... +55 ?
Humidity 10... 95%rH, not condensing
PoE (Power over
Ethernet)
in accordance with IEEE 802.3af (12.95 W)
and IEEE802.3at (25.5 W)
Supported supply process:
• Spare pair supply:
via fast Ethernet, free 4/5 and 7/8 core pairs
• Phantom supply:
via RX cores (1/2) and TX cores (3/6)
The power supply is superimposed on the
data signal.
Interfaces
Network Ethernet interface 10Base-T/100Base-TX
