Mounting and installation User Manual B-Net 93 60
24 © Kaba Benzing GmbH 01/2006
5.4.3 Using the mounting plate
If you install the terminal using the mounting plate, the terminal can be quickly and
easily removed from the wall.
Remark
The mounting plate --product number 04036599-- is an optional accesssory and
must therefore be ordered separately!
To mount the plate to the wall, 3 drill holes are provided.
After you attach the mounting plate to the wall, attach the terminal to the mounting
plate using the two mounting holes on the back of the terminal. For protection,
tighten the knurled screw at the lower end of the plate.
Fig. 10: Terminal and mounting plate
Fig. 11: Wall mounting with mounting plate
