TECHNICAL DESCRIPTION flowIQ® 3100
14 Kastup A/S • Tehial Desiptio • 5512-1242_D_GB • 09.2016
260
6 Dimensioned sketches
Type:
A Q
3
1.6 m³/h – G¾B (R½) x 110 mm
B Q
3
2.5 m³/h – G¾B (R½) x 110 mm
C Q
3
2.5 m³/h – G1B (R¾) x 190 mm
2 Q
3
2.5 m
3
/h – G5/4B (R1) x 175 mm
3 Q
3
4.0 m
3
/h – G5/4B (R1) x 175 mm
G Q
3
4.0 m³/h – G5/4B x 260 mm
H Q
3
6.3 m³/h – G5/4B x 260 mm
J Q
3
10 m³/h – G2B x 300 mm
190
175
300
110
