TECHNICAL DESCRIPTION flowIQ® 3100
42 Kastup A/S • Tehial Desiptio • 5512-1242_D_GB • 09.2016
10.5 Meter modes (settings)
The water meter has 2 modes:
(measurement/calculation)
Verification mode is only used by authorised laboratories during verification.
10.6 Normal mode
Normal mode is meant for normal operation.
In normal mode, the volume unit symbol m
3
displays. Futheoe, the to suae dots at the otto
right of the display shift every second.
The flow is measured every four seconds and new values (flow, volume, etc.) are calculated every 32
seconds.
10.7 Verification mode
Verification mode is meant for verification of the meter.
I the displa, eifiatio ode ill e idiated the olue uit sol L. In addition, the 2 dots at
the bottom right of the display are changing twice per second.
The flow is measured twice per second and new values (flow, volume, etc.) are calculated every four
seconds.
Whe the ete sithes to eifiatio ode, the ieless M-Bus radio transmitter will be turned off. At
the same time a time-out starts. When the time-out period has expired the meter switches back to normal
mode. The time-out period is 9 hours.
10.8 Legal changes outside seal
This paragraph describes the legal changes, which can be carried out without disassembling the meter and
thereby breaking the legal seal.
All legal changes are fully traceable in an adjust log, which cannot be deleted. The number of legal changes
appears from the display (see paragraph
Adjustment mark). Maximum 9 changes are possible.
The adjust log can only be deleted if the meter is disassembled and the legal seal is broken.
It appeas fo the etes softae esio hethe a speifi ete an be reset outside the legal seal.
See support of legal changes below:
= Supported
