MULTICAL® 602 & ULTRAFLOW®
Type 67-09: ∆Volume clcultion nd hourly dt logger
This top module clcultes the difference between inlet nd outlet
volume, whereby n expression of the tpped volume in open systems
is obtined.
Differentil volume dV=V1-V2.
The module lso includes n hourly dt logger.
The connection terminls re not used in this module.
Type 67-0A: 2 pulse outputs for CE nd CV + hourly dt logger +
scheduler
The top module hs the sme functions s top module 602-0C.
Furthermore, the module cn simulte  cold wter temperture
ccording to  progrmmed scheduler, in which T2, T3 or T4 cn be
progrmmed with up to 12 individul dtes/tempertures per yer.
Type 67-0B: 2 pulse outputs for CE nd CV + prog. dt logger
The RTC nd pulse output functions of this top module re identicl
with the functions described for top module 602-0C (see below).
The top module is prepred for use in  Kmstrup rdio network
together with High Power RdioRouter bse module 6020084, red
dt being trnsferred to the system softwre vi the network unit RF
Concentrtor.
Type 602-0C: 2 pulse outputs for CE nd CV
This top module hs two configurble pulse outputs, which re
suitble for volume nd energy pulses for het meters, cooling meters
nd combined het/cooling meters.
The pulse resolution follows the disply (determined by the CCC-
code). E.g. CCC=119 (q
p
1,5): 1 pulse/kWh nd 1 pulse/0.01 m
3
.
The pulse outputs re optoisolted nd withstnd 30 VDC nd 10 mA.
Normlly energy (CE) is connected to 16-17 nd volume (CV) to 18-19,
but other combintions cn be selected by mens of the PC progrm
METERTOOL, which is lso used for selecting the pulse durtion t
either 32 or 100 ms.
