2 Kamstrup A/S • 5512952_C6_GB_07.2015
MULTICAL® 602 & ULTRAFLOW®
MID designtions
Permissible operting conditions / mesuring rnges
Clcultor q: 2 °C…180 °C : 3K…170K
Temperture sensor pir q: 10 °C…150 °C : 3K…140K
Flow sensor q: 15 °C…130 °C
Mechnicl environment
M1 (fixed instlltion with minimum vibrtion).
M2 (significnt or high level of vibrtion nd shock - Flow sensor type 65-5-XXHX-XXX only).
Electromgnetic environment
E1 nd E2 (domestic/light industry nd industry). The meter’s control cbles must be drwn t min.
25 cm distnce to other instlltions.
Climtic environment
Must be instlled in environments with non-condensing humidity s well s in closed loctions
(indoors). The mbient temperture must be within 5…55 °C.
Mintennce nd repir
The district heting supplier cn replce communiction module, bttery, temperture sensor pir
nd flow sensor. The flow sensor is verified seprtely nd cn, therefore, be seprted from the
clcultor.
Other repirs require subsequent reverifiction in n ccredited lbortory.
MULTICAL® 602, type 602-B/C/D must be connected to  temperture sensor pir type Pt500.
MULTICAL® 602, type 602-A must be connected to  temperture sensor pir type Pt100.
MULTICAL® 602, type 602-A/B/C cn be connected to flow sensor type ULTRAFLOW®, electronic
pick-up, or flow sensors with reed switch output.
MULTICAL® 602, type 602-D must be connected to  flow sensor with 24 V ctive pulse output.
Irrespective of flow sensor type, “pulses/litre must be identicl in flow sensor nd clcultor.
Bttery for replcement
Kmstrup type 1606064.
