9.2.3 Rdio + pulse inputs, 67-00-21/25/26
The rdio module is used for wireless
communiction
vi licence-free rdio frequency nd cn
be supplied with internl ntenn or with
connection for externl ntenn.
For further informtion on rdio we refer to
Technical description for radio (5512-013).
The pulse inputs of this module re identicl
with the previously described pulse inputs.
Note: Type 67-00-21 includes rdio nd router
functions.
The RdioRouter module (67-00-21)
must be used with mins supply.
9.2.4 Prog. dt logger + RTC + 4…20 mA inputs + pulse inputs, type 67-00-22
The module hs connection possibility for two pressure trnsmitters on terminls 57, 58 nd 59
nd cn be djusted for current reding or pressure rnge 6, 10 or 16 br.
The module is prepred for remote reding, dt from meter/module being trnsferred to the
system softwre vi the externl GSM/GPRS modem connected on terminls 62, 63 nd 64.
Furthermore, the module hs two extr pulse inputs, VA nd VB.
The module must be powered by 24 VAC.
9.2.5 Anlog outputs, type 67-00-23
See installation instructions 5512-369 (DK-GB-DE).
9.2.6 LonWorks + pulse inputs, type 67-00-24
See installation instructions 5512-396 (DK) or 5512-403 (GB).
9.2.7 Wireless M-Bus + pulse inputs, type 602-00-30/602-00-35/602-00-38
The rdio module hs been designed to form prt of the hnd-held Wireless M-Bus Reder
systems of Kmstrup A/S t license-free rdio frequency (868 MHz).
The module fulfils the C-mode specifictions of EN13757-4 nd cn thus form prt of other
systems using Wireless M-Bus C-mode communiction.
The rdio module comes with internl ntenn nd externl ntenn connection s well s two
pulse inputs, which re identicl with the previously described pulse inputs.
The Wireless M-Bus rdio trnsmitter is switched off on disptch from the fctory. It turns on
utomticlly when one litre of wter hs run through the meter. The rdio trnsmitter cn lso be
switched on by mens of  forced dil-up to the meter (keep both front keys pressed for pprox. 5
s until CALL is displyed).
