MULTICAL® 602 & ULTRAFLOW®
A Recommended flow sensor position.
B Recommended flow sensor position.
C Uncceptble position due to risk of ir build-
up.
D Acceptble in closed systems. Uncceptble
position in open systems due to risk of ir
build-up in the system.
E A flow sensor ought not to be plced
immeditely fter  vlve, with the exception
of block vlves (bll vlve type) which must
be fully open when not used for blocking.
F A flow sensor should not be plced t the
suction side of  pump.
G A flow sensor ought not to be plced fter 
double bend in two levels.
A
B
C
D
E
F
G
In order to prevent cvittion the bck pressure (the pressure t the flow sensor outlet) t
ULTRAFLOW® must be min. 1.5 br t q
p
nd min. 2.5 br t q
s
. This pplies to tempertures up to
pprox. 80 °C.
ULTRAFLOW® must not be exposed to lower pressure thn the mbient pressure (vcuum).

Kamstrup MULTICAL 602 Specifications

General

Flow Sensor	Ultrasonic
Display	LCD
Battery Life	Up to 16 years
Communication	M-Bus, Wireless M-Bus
Approval	MID class 2, EN 1434
Accuracy	Class 2
Pressure Rating	PN16
Application	Heating and cooling systems
Temperature Range	0°C to 180°C
