9.2 Sensor types
MULTICAL® 803 can be supplied with both Pt100 and Pt500 sensor pairs. The required sensor pair is selected
through the calculator’s type number. The table below shows the available sensor pairs. See the calculator's
complete type number in paragraph 3.1.
Description
Pt100 / Pt500
Sensor
number
2 sets of Direct short 27.5 mm, 1.5 m cable
Pt500
11
2 sets of Direct short 27.5 mm, 3 m cable
Pt500
12
3 sets of Direct short 27.5 mm, 1.5 m cable
Pt500
15
3 sets of Direct short 27.5 mm, 3 m cable
Pt500
16
2 sets of Direct short 38 mm, 1.5 m cable
Pt500
21
2 sets of Direct short 38 mm, 3 m cable
Pt500
22
2 sets of ø5.8 mm pocket sensor, 1.5 m cable
Pt500
31
2 sets of ø5.8 mm pocket sensor, 3 m cable
Pt500
32
2 sets of ø5.8 mm pocket sensor, 5 m cable
Pt500
33
2 sets of ø5.8 mm pocket sensor, 10 m cable
Pt500
34
3 sets of ø5.8 mm pocket sensor, 1.5 m cable
Pt500
35
3 sets of ø5.8 mm pocket sensor, 3 m cable
Pt500
36
3 sets of ø5.8 mm pocket sensor, 5 m cable
Pt500
37
3 sets of ø5.8 mm pocket sensor, 10 m cable
Pt500
38
2 sets of Direct short 27.5 mm, 2 m cable Pt100 J1
2 sets of Direct short 38 mm, 2 m cable
Jx
Pt100
J2
2 sets of ø6 mm with connection head, length 105 mm
Pt100
A1
2 sets of ø6 mm with connection head, length 140 mm Pt100 A2
2 sets of ø6 mm with connection head, length 230 mm
Pt100
A3
2 sets of ø6 mm with connection head, length 105 mm
Pt500
A4
2 sets of ø6 mm with connection head, length 140 mm Pt500 A5
2 sets of ø6 mm with connection head, length 230 mm
Pt500
A6
2 sets of ø5.8 mm pocket sensor in pocket with connection head, length 90 mm
Pt500
B1
2 sets of ø5.8 mm pocket sensor in pocket with connection head, length 140 mm Pt500 B2
2 sets of ø5.8 mm pocket sensor in pocket with connection head, length 180 mm
Pt500
B3
