3.4.6 Tariff limits with Auto Detect UF of ULTRAFLOW® X4
Auto Detect UF enables the exchange of ULTRAFLOW® X4 on MULTICAL® 803 without the need for changing the CCC
code. MULTICAL® 803 can automatically adjust its CCC code to match the connected ULTRAFLOW® X4 via the
function Auto Detect UF. Auto Detect UF is active with the CCC code 8xx. Read more about it in paragraph 8.1.1.
The resolution of the tariff limits is adapted to the nominal flow qp and is thus controlled by the selected CCC code.
The tariff limits do not change value by Auto Detect UF, but the value resolution and device can change. An example
with a flow-controlled tariff is shown below.
Qp = 1.5 m
3
/h
Tariff limit, TL2
Used/Display: 350 l/h
Base resolution (stored in the calculator):
350 l/h
- Auto Detect -
Qp = 150 m
3
/h
Tariff limit, TL2
Used/Display: 0.3 m
3
/h
Base resolution (stored in the calculator):
350 l/h
Reconfiguration
of tariff limits
Qp = 150 m
3
/h
Tariff limit, TL2
Used/Display: 0.2 m
3
/h
Base resolution (stored in the calculator):
200 l/h
- Auto Detect - - Auto Detect -
Qp = 1.5 m
3
/h
Tariff limit, TL2
Used/Display: 350 l/h
Base resolution (stored in the calculator):
350 l/h
Qp = 1.5 m
3
/h
Tariff limit, TL2
Used/Display: 200 l/h
Base resolution (stored in the calculator):
200 l/h
