Kamstrup MULTICAL 803 Technical Description

MULTICAL® 803
162
Kamstrup A/S · Technical description · 5512-2360_A1_GB_02.2019
11.6 Retrofitting modules
Modules for MULTICAL

803 are also supplied separately for retrofitting. See paragraph 3.2 for guidelines for the
combination of modules.
The modules are factory-configured and ready for installation. However, some modules require individual final
configuration that can be performed by means of METERTOOL HCW. See the technical description of METERTOOL
HCW (5512-2097) for further information.
Note: Before modules are replaced or installed, the supply to the calculator must be disconnected. The same applies
to the mounting of an antenna.
Type
no.
Module
Possible configuration after installation
10
Data
+ 2 pulse inputs (In-A, In-B)
Meter factor and preset of In-A and In-B can be changed
via METERTOOL HCW.
11
Data
+ 2 pulse outputs (Out-C, Out-D)
Pulse duration of Out-C and Out-D can be changed via
METERTOOL HCW.
20
M-Bus
+ 2 pulse inputs (In-A, In-B)
Meter factor and preset of In-A and In-B can be changed
via METERTOOL HCW.
Primary and secondary M-Bus addresses can be changed
via METERTOOL HCW or M-Bus. The register content of
the M-Bus data package can be changed via METERTOOL
HCW and READy.
21
M-Bus
+ 2 pulse outputs (Out-C, Out-D)
Pulse duration of Out-C and Out-D can be changed via
METERTOOL HCW.
Primary and secondary M-Bus addresses can be changed
via METERTOOL HCW or M-Bus. The register content of
the M-Bus data package can be changed via METERTOOL
HCW and READy.
22
M-Bus
+ Thermal Disconnect
Primary and secondary M-Bus addresses can be changed
via METERTOOL HCW or M-Bus. The register content of
the M-Bus data package can be changed via METERTOOL
HCW and READy.
30
Wireless M-Bus
+ 2 pulse inputs (In-A, In-B)
Meter factor and preset of In-A and In-B can be changed
via METERTOOL HCW. The register content of the M-Bus
data package can be changed via METERTOOL HCW and
READy.
31
Wireless M-Bus
+ 2 pulse outputs (Out-C, Out-D)
Meter factor and preset of Out-C and Out-D can be
changed via METERTOOL HCW. The register content of
the M-Bus data package can be changed via METERTOOL
HCW and READy.
40
Analog output module, with 2 x 0/4…20 mA
Output as 0…20 mA or 4…20 mA. Output from one of the
following registers: Flow V1, power, inlet temperature t1,
outlet temperature t2, differential temperature t1-t2.
The above values can be changed via METERTOOL HCW
and are individual for each of the two outputs.
