Instructions for use DSE Expert
4 First use | 4.1 Fitting and connecting
26 / 74
4 First use
4.1 Fitting and connecting
4.1.1 Connect power, air and water
DANGER
Electrical power.
Electrical shock
▶ If the light is attached, pull the mains plug of the unit and of the light or disconnect
all poles of the unit from the voltage source.
CAUTION
Splashing water
Electrical shock
▶ Place the customer-site power outlets appropriately such that any ingress of
splashing water from the simulation unit is prevented.
CAUTION
Connecting lines from the simulation unit to the customer-site supply connectors.
Injuries and electrical shock
▶ Route the connecting lines from the unit's connector and the power outlet appro-
priately such that there is no risk of tripping and such that the cable does not get
damaged during the positioning (travel) of the simulation unit. Route the connect-
ing lines appropriately such that the are protected by the strain relief of the simu-
lation unit.
Note
Connections to drinking water lines must comply with local, national regulations. In
Europe, compliance with DIN EN 1717 is required.
Install dentist element and assistant element (optional).
▶ Remove the dentist element ① with support arm from the packaging and plug it in
the holder ②
▶ Remove the assistant element ③ (if any) with support arm from the packaging
and plug it in the holder ②
▶ Hook the tray (optional) ④ in the tray holder of the assistant element.
