KEB C6-COMPACT User Manual

GB - 11
KEB COMBICONTROL
2.2.5 Adapter cable HSP5 interface operator
Screw terminal:
Color see below
C6 PCC
X1A…H
Signal TXD+ TXD- GND RXD+ RXD- GND EnTXD+ EnTXD-
PIN 1 2 3 4 5 6 7 8
| | | | | | | |
PIN 4 3 9 2 1 9 8 7
Operator
X6E
Signal RXD+ RXD- GND TXD+ TXD- GND EnRxD+ EnRxD-
Color see below
RJ45 connection:
Color see below
C6 PCC
X1A...H
Signal TXD+ TXD- GND RXD+ RXD- GND EnTXD+ EnTXD-
PIN 1 2 3 4 5 6 7 8
| | | | | | | |
PIN 1 2 3 4 5 6 7 8
Operator
RJ45
Signal RXD+ RXD- GND TXD+ TXD- GND EnRxD+ EnRxD-
Color see below
In case of production of own connecting cables please pay attention that the
signal pairs (e.g. TxD+ and TxD -) are assigned to the corresponding twisted
cables (e.g. green and green/white). Connect unused scores always to GND.
2.2.6 Comparison of the standards
Pair PIN EIA/TIA 568B EIA/TIA 568A DIN 47100 IEC 189.2 USOC
3 1 orange/white green/white green red black
3 2 orange green yellow orange yellow
2 3 green/white orange/white gray black orange
1 4 blue blue brown blue red
1 5 blue/white blue/white white white green
2 6 green orange pink green brown
4 7 brown/white brown/white blue yellow gray
4 8 brown brown red brown blue
