KEB C6-COMPACT User Manual

GB - 25
KEB COMBICONTROL
et.11
Subnet mask
Address 030Bh
The decision whether an IP slave address is outside of the own network is determined with
this mask. The mask presents as follows: 0.0.0.0 the standard masks are used depending
on network classes A, B or C. In case of doubt the subnet mask to be adjusted can be ask
for by the network administrator.
The correct subnet mask must be adjusted for the connection with the program-
ming system!
et.12
data port response delay
Address 030Ch
This parameter adjusts the response delay for the port 8001 in ms. The network utilization
can be reduced by setting of higher values. A value of 0 enables the fastest communica-
tion with the control, but a high network utilization is also generated.
et.14
Link state
Address 030Eh
Displays state informations for the Ethernet link.
et.15
Link mode
Address 030Fh
Determines the adjustments of the Ethernet interface. Fixed values or automatic recogni-
tion can be adjusted here. The additional clearlock value 32 activates a special behaviour,
which corrects link problems automatically with automatic detection on both sides (control
and switch).
3.3.2 Real-time clock
The internal realtime clock is adjusted and/or read-out with the following parameters:
rc.00
time
Address 0400h
This parameter displays the time in hours and minutes in a 24-hours format. Writing on
this parameter adjusts the time.
rc.01
seconds
Address 0401h
This parameter displays the seconds in a range of 0...59. Writing on this parameter ad-
justs the seconds.
rc.02
date
Address 0402h
This parameter displays the date in a DD-MM format. Writing on this parameter adjusts
the date.
rc.03
year
Address 0403h
This parameter displays the year in four digits. Writing on this parameter adjusts the year.
