KEB C6-COMPACT User Manual

GB - 6
KEB COMBICONTROL
Axis interface X1A ... X1D
Type HSP5/485
Connector RJ-45, 8-pole, screened
Cable Cat5, max. 100 m
Speed 38.4…250 kBaud
Using Connection to KEB F5 inverter/servo, process
data transmission, communication channel
Ethernet interfaces X6B, X6C
Type IEEE802.3
10/100BaseTx
Connector RJ-45, 8-pole, screened
Speed 10/100 MBaud
autocrossover
Using Connection to programming system (debugging,
visualization).
Connection to parameterizing system (control
and axis adjustment, scope).
Connection to any devices
(SysSocket). Die 2. Ethernet interface X6C is
only accessible by the IEC program and is used
e.g. for the EtherCAT master.
Serial interface
Type DIN66019II, RS232, RS485 full/half duplex
Connector D-Sub 9 female
Speed 9.6…115.2 kBaud
Using Connection to parameterizing system
(control and axis adjustment, scope).
Connection to any devices
(SysCom).
Memory of the programming system
The program memory size (code, data, ags, input, output) is not limited and depends
only on the available free total memory (max. 32 MBytes).

KEB C6-COMPACT Specifications

General

Brand	KEB
Model	C6-COMPACT
Category	Control Unit
Language	English
