Functional Description Set Value and Ramp Adjustment
Chapter Section
Page Date
oP.0 Set value Direction of rotation
0 Analog (±REF / REF) digital (oP.3)
1 Analog (±REF / REF) terminal strip
2 Analog (±REF / REF) sign of setpoint value
3 Digital absolute (oP.1) digital (oP.3)
4 Digital absolute (oP.1) terminal strip
5 Digital absolute (oP.1) sign of setpoint value
6 Digital percent (oP.2) digital (oP.3)
7 Digital percent (oP.2) terminal strip
8 Digital percent (oP.2) sign of setpoint value
9 Profile parameter absolute (Pr.8) digital (oP.3)
10 Profile parameter absolute (Pr.8) terminal strip
11 Profile parameter absolute (Pr.8) sign of setpoint value
12 Profile parameter percent (Pr.38) digital (oP.3)
13 Profile parameter percent (Pr.38) terminal strip
14 Profile parameter percent (Pr.38) sign of setpoint value
15 Motor-poti digital (SP.3)
16 Motor-poti terminal strip
17 Motor-poti sign of setpoint value
18 PI-Controller manipulated variable digital (oP.3)
19 PI-Controller manipulated variable terminal strip
20 PI-Controller manipulated variable sign of setpoint value
21 Speed detection channel 1 digital (oP.3)
22 Speed detection channel 1 terminal strip
23 Speed detection channel 1 sign of setpoint value
24 Speed detection channel 2 digital (oP.3)
25 Speed detection channel 2 terminal strip
26 Speed detection channel 2 sign of setpoint value
