KEB COMBIVERT F4-C Applications Manual

7
ANTRIEBSTECHNIK
2
17
KEB COMBIVERT F4-C
Name: Basis
09.04.99
2
© KEB Antriebstechnik, 1999
All Rights reserved
Product Description Summary
Section
Page
Date
Chapter
2.1.7 Unit Sizes 400V-Class (07-17)
1) From housing size M fuses of Type Ferra Z 6,6 URD xxx must be used.
2) This data is only valid for units with internal brake transistor (see „2.1.4 Type Code“).
3) At mains voltage ≥460V multiply the nominal current with factor 0,86.
4) These units can be used with one or more braking modules. For more informations cantact KEB.
Inverter Size 07 09 10 12 13 14 15 16 17
Output nominal power [kVA] 1,8 2,8 4 6,6 8,3 11 17 23 29
Max. rated motor power [kW] 0,8 1,5 2,2 4 5,5 7,5 11 15 18,5
Output nominal current [A] 2,6 4,1 5,8 9,5 12 16,5 24 33 42
Max. short-time current [A] 4,6 7,4 10,4 17,1 21,6 18 30 25 36 49,5 63
OC-tripping current [A] 5,7 9 12,7 20,9 26,4 22 36 30 43,2 59,4 75,6
Nominal input current [A] 2,8 4,5 6,4 10,5 13,2 18,1 26,5 36,5 46
Housing size DDDDDEDEGEGEGHGHGHR
Rated operating frequency [kHz] 4 4 4 12 4 16 2 16 8 16 4 8 16 8 16 4 8 16
Max.operating frequency [kHz] 4 4 4 12 4 16 4 16 16 16 12 16 16 16 16 16 16 16
Power loss at nominal operating [W] 45 60 80 130 115 180 135 240 200 240 260 260 290 360 310 490 360 470 700
Stall current at 8kHz [A] - - - 6,4 - 9,5 - 12 19 17 19 - 19 25 22 33 - 30 42
Stall current at 16kHz [A]-----9,5-1212-12-8,5159,720-1430
Max. heat sink temperatureT
OH
[°C] 85 79 85 73 79 73 90 73 90 73 90 90 90 79
Max. permissible mains fuse (inert)
1)
[A]1010202025355063
Line cross section [mm²] 1,5 1,5 2,5 2,5 4 6 10 16
Min. braking resistor
2)
[
Ω
] 160 160 82508250395039 39 2225222522 9
Typ. braking resistor
2)
[
Ω
] 390 270 150 100 82 56 39 28
Max. braking current [A] 5 10151015211521 21 373037303788
Tightening torque for terminals [Nm] 0,5 1,2 0,5 1,2 0,5 1,2 2,5 1,2 2,5
Mains voltage
3)
[V]
305...500 +/-0 (400V Nominal voltage)
1)
Phases 3
Mains frequency [Hz] 50 / 60 +/- 2
Output voltage [V] 3 x 0...U Mains
Output frequency [Hz] see control board
Shielded motor line length [m] 50 50 100 100 100 100 100 100 100
Storage temperature [°C] -25...70 °C
Operating temperature [°C] -10...45 °C
Model / protective system IP20
Relative humidity max. 95% without condensation
Tested in accordance with... EN 61800-3
Climatic category 3K3 in accordance with EN 50178
