Relay output The relay output (terminal X1.1…X1.3) is factory adjusted as fault relay. With this
parameter the function of the output can be adjusted to any function listed in the
following table.
Value Function
0 no function (generally off)
1 generally on
2 fault relay
3 fault relay (not in case of undervoltage error)
4 overload warning
5 overtemperature warning inverter
6 overtemperature motor OH-terminals (switch off after 10s)
7 only for application mode
8 max. constant current (Stall, CP.15) exceeded
9 max. ramp current (LA-/LD-Stop, CP.14) exceeded
10 DC-braking active
11 only for application mode
12 load (CP.3) > 100%
13 only for application mode
14 actual value = setpoint value (CP.2= Fcon, rcon; not at noP, LS, error, SSF)
15 acceleration (CP.2 = FAcc, rAcc, LAS)
16 deceleration (CP.2 = FdEc, rdEc, LdS)
17 clockwise rotation (not at noP, LS, error)
18 counter-clockwise rotation (not at noP, LS, error)
19 actual direction of rotation = set direction of rotation
20 actual value > frequency level CP.23 (only S-Version)
21 setpoint value > frequency level CP.23 (only S-Version)
22 only for application mode
23 ready-for-operation signal (after initialization provided no error exists)
24 Run-Signal ( modulation on)
25 only for application mode
Factory setting: 2
Remarks: Enter-Parameter
Customer setting: _______
This parameter defines the switching point for the relay output.
- X1.21...X1.23 (only C-Version)
- X1.1...X1.3 (only S-Version at CP.22 value "20" or "21"
After the switching of the relay the frequency can move within a window of 0.5 Hz
without causing the relay to drop out.
Setting range: 0,0...409,58 Hz
Resolution: 0,0125 Hz
Factory setting: 4 Hz
Customer setting: _______
