KEB COMBIVERT F5 BASIC User Manual

6
123
24.06.02
KEB COMBIVERT F5-G / B
Name: Basis
6
Functional Description
© KEB Antriebstechnik, 2002
All rights reserved
Chapter Section PageDate
Operating and Appliance Data
Adr.
min max
default
0032h
1
-
0
655350
Sy. 50 Control word
The control word is used for the status control of the inverter via bus. The control word long (Sy.43) consists of the two
16 bit parameters control word high (Sy.41) and Control word low (Sy.50). Das Steuerwort ist bitcodiert. The status word
is bit-coded. The description of the individual bits is found in Chapter 11.2.7.
Adr.
min max
default
0033h
1
-
0
655350
Sy. 51 Status word
With the status word the current condition of the inverter can be readout. The status word long (Sy.44) consists of the
two 16 bit parameters status word high (Sy.42) and status word low (Sy.51). Das Steuerwort ist bitcodiert. The status
word is bit-coded. The description of the individual bits is found in Chapter 11.2.7.
Adr.
min max
default
0034h
1
rpm
0
16000-16000
Sy. 52 Set speed value
Presetting of the setpoint speed in the range of ±16000 rpm. The source of direction of rotation is determined as with the
other absolute setpoint sources over oP.1. The setpoint source oP.0 must be adjusted to „5“ for setpoint setting by
Sy.52.
Adr.
min max
default
002Bh
1
-
0
2147483647-2147483648
Sy. 43 Control word long
The control word is used for the status control of the inverter via bus. The control word long (Sy.43) consists of the two
16 bit parameters control word high (Sy.41) and Control word low (Sy.50). The status word is bit-coded. The description
of the individual bits is found in Chapter 11.2.7.
Adr.
min max
default
002Ch
1
-
0
Sy. 44 Status word long
With the status word the current condition of the inverter can be readout. The status word long (Sy.44) consists of the
two 16 bit parameters status word high (Sy.42) and status word low (Sy.51). The status word is bit-coded. The description
of the individual bits is found in Chapter 11.2.7.
2147483647-2147483648
