Page 7.16 - 8 COMBIVERT F5-A, -E, -H © KEB, 2012-10
CP-Parameterdenition
unstandardized value = standardized value / resolution
Table 3 Representation (Bit 8...11)
Value Representation
0 0 decimal places
256 1 decimal place
512 2 decimal places
768 3 decimal places
1024 4 decimal places
1280 variable decimal places
1536 Hexadecimal
- free
Example
The actual frequency shall be displayed in CP.1 in rpm. Display standardization from set 4.
ud.15 = 1 ; CP.1
ud.16 = 0203h ; Actual frequency ru.3
ud.17 = 4352 ; Display in the actual set, display norm from set 4
Set 4 ud.18 = 80 ; Conversion from 1/80 Hz into rpm without pole-pair number
Set 4 ud.19 = 60
Set 4 ud.20 = 0 ; ; no Offset
Set 4 ud.21 = 17 ; Unit rpm; direct calculation mode;no decimal place
