KEB COMBIVERT F5-H User Manual

Page 11.1 - 8 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Parameter
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
di.42 I2 activation delay 0B2Ah appl np – 0 32.00 0 0.01 s
di.43 I2 deactivation delay 0B2Bh appl np – 0 32.00 0 0.01 s
di.44 I3 activation delay 0B2Ch appl np – 0 32.00 0 0.01 s
di.45 I3 deactivation delay 0B2Dh appl np – 0 32.00 0 0.01 s
di.46 I4 activation delay 0B2Eh appl np – 0 32.00 0 0.01 s
di.47 I4 deactivation delay 0B2Fh appl np – 0 32.00 0 0.01 s
di.48 IA activation delay 0B30h appl np – 0 32.00 0 0.01 s
di.49 IA deactivation delay 0B31h appl np – 0 32.00 0 0.01 s
di.50 IB activation delay 0B32h appl np – 0 32.00 0 0.01 s
di.51 IB deactivation delay 0B33h appl np – 0 32.00 0 0.01 s
di.52 IC activation delay 0B34h appl np – 0 32.00 0 0.01 s
di.53 IC deactivation delay
0B35h appl np – 0 32.00 0 0.01 s
di.54 ID activation delay 0B36h appl np – 0 32.00 0 0.01 s
di.55 ID deactivation delay 0B37h appl np – 0 32.00 0 0.01 s
do.00 condition 0 0C00h appl P E 0 92 20 1 ---
7.3 - 14,7.3 - 16,7.3 - 17,7.3
- 22,7.3 - 26,7.12 - 11,7.12 -
48,7.12 - 49,7.12 - 75
do.01 condition 1 0C01h appl P E 0 92 3 1 --- 7.3-23, 7.3-26, 7.12-49
do.02 condition 2 0C02h appl P E 0 92 4 1 --- 7.3-26, 7.12-49
do.03 condition 3 0C03h appl P E 0 92 2 1 --- 7.12-49
do.04 condition 4 0C04h appl P E 0 92 0 1 --- 7.5-26, 7.12-49
do.05 condition 5 0C05h appl P E 0 92 0 1 ---
do.06 condition 6 0C06h appl P E 0 92 0 1 ---
do.07 condition 7 0C07h appl P E 0 92 0 1 ---
7.3-14, 7.3-16, 7.3-17, 7.3-
22, 7.12-75
do.08 inv. cond. for ag 0 0C08h appl P E 0 255 0 1 --- 7.1-8, 7.3-16, 7.3-22
do.09 inv. cond. for ag 1 0C09h appl P E 0 255 0 1 --- 7.3-23
do.10 inv. cond. for ag 2 0C0Ah appl P E 0 255 0 1 --- 7.3-26
do.11 inv. cond. for ag 3 0C0Bh appl P E 0 255 0 1 ---
do.12 inv. cond. for ag 4 0C0Ch appl
P E 0 255 0 1 ---
do.13 inv. cond. for ag 5 0C0Dh appl P E 0 255 0 1 ---
do.14 inv. cond. for ag 6 0C0Eh appl P E 0 255 0 1 ---
do.15 inv. cond. for ag 7 0C0Fh appl P E 0 255 0 1 --- 7.3-16, 7.3-22
do.16 cond. select. for ag 0 0C10h appl P E 0 255 1 1 ---
7.3-16, 7.3-23, 7.3-26,
7.12-48
do.17 cond. select. for ag 1 0C11h appl P E 0 255 2 1 --- 7.3-26, 7.12-49
do.18 cond. select. for ag 2 0C12h appl P E 0 255 4 1 --- 7.3-26, 7.12-49
do.19 cond. select. for ag 3 0C13h appl P E 0 255 8 1 --- 7.12-49
do.20 cond. select. for ag 4 0C14h appl P E 0 255 16 1 ---
do.21 cond. select. for ag 5 0C15h appl P E 0 255 32 1 ---
do.22 cond. select. for ag 6 0C16h appl P E 0 255 64 1 ---
do.23 cond. select. for ag 7 0C17h appl P E 0 255 128 1 ---
7.3-14, 7.3-20
do.24 AND/OR conn. for ags 0C18h appl P E 0 255 0 1 ---
7.3 - 16,7.3 - 23,7.3 - 26,7.1
2 - 49
do.25 inv. ags for O1 0C19h appl P E 0 255 0 1 --- 7.3-16, 7.3-24, 7.3-26
do.26 inv. ags for O2 0C1Ah appl P E 0 255 0 1 ---
do.27 inv. ags for R1 0C1Bh appl P E 0 255 0 1 --- 7.3-26
do.28 inv. ags for R2 0C1Ch appl P E 0 255 0 1 ---
do.29 inv. ags for OA 0C1Dh appl P E 0 255 0 1 ---
do.30 inv. ags for OB 0C1Eh appl P E 0 255 0 1 ---
do.31 inv. ags for OC 0C1Fh appl P E 0 255 0 1 --- 7.12-50
do.32 inv. ags for OD 0C20h appl P E 0 255 0 1 --- 7.3-24
do.33 ag select. for O1 0C21h appl P E 0 255 1 1 ---
7.3 - 16,7.3 - 24,7.3 - 26,7.1
2 - 48
do.34 ag select. for O2 0C22h appl P E 0 255 2 1 --- 7.3-26
do.35 ag select. for R1 0C23h appl P E 0 255 4 1 --- 7.3-26
do.36 ag select. for R2 0C24h appl P E 0 255 8 1 --- 7.3-4
do.37 ag select. for OA 0C25h appl P E 0 255 16 1 --- 7.12-49
do.38 ag select. for OB 0C26h appl P E 0 255 32 1 ---
do.39 ag select. for OC 0C27h appl P E 0 255 64 1 --- 7.12-50
do.40 ag select. for OD 0C28h appl P E 0 255 128 1 --- 7.3-24
do.41 AND conn. for outputs 0C29h appl P E 0 255 0 1 ---
7.3 - 4,7.3 - 16,7.3 - 24,7.3 -
26,7.12 - 49
do.42 inverted outputs 0C2Ah appl P E 0 255 0 1 --- 7.3-16, 7.3-24
do.43 cond. 0 lter time 0C2Bh appl P --- 0 1000 0 1 ms 7.3-16
do.44 cond. 1 lter time 0C2Ch appl P --- 0 1000 0 1 ms 7.3-16
do.51 hardw. output allocation 0C33h appl P E 0 255 228 1 ---
7.1-14,7.3-16,7.3-25,7.3-
26,10.1-11
dr.00 DASM rated current 0600h appl P --- 0.0 1100.0 LTK 0.1 A
6.2 - 5,6.2 - 7,6.2 - 10,6.2 - 1
4,7.5 - 8,7.5 - 12,7.5 - 16,7.5
- 23,7.11 - 24,7.15 - 5
further on next side
