KEB COMBIVERT F5-H User Manual

Parameter
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 11.1 - 9
10
11
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
dr.01 DASM rated speed 0601h appl P --- 0 64000 ; 8000 LTK
1 ;
0.125
rpm
5.1 - 4,6.2 - 5,6.2 - 7,6.2 - 10,
6.2 - 14,7.5 - 8,7.5 - 12,7.5 -
25,7.11 - 24
dr.02 DASM rated voltage 0602h appl P --- 120 830 LTK 1 V
6.2 - 5,6.2 - 7,6.2 - 10,6.2 - 1
4,7.5 - 8,7.5 - 9,7.5 - 12,7.1
1 - 24
dr.03 DASM rated power 0603h appl P --- 0.10 1000.00 LTK 0.01 kW
6.2 - 7,6.2 - 10,6.2 - 14,7.2 -
13,7.5 - 8,7.5 - 12,7.7 - 3,7.
11 - 24
dr.04 DASM rated cos (phi) 0604h appl P --- 0.50 1.00 LTK 0.01 ---
6.2 - 5,6.2 - 7,6.2 - 10,6.2 - 1
4,7.5 - 8,7.5 - 16,7.11 - 24
dr.05 DASM rated frequency 0605h appl P --- 0.0 1600.0 LTK 0.1 Hz
6.2 - 5,6.2 - 7,6.2 - 10,6.2 - 1
4,7.5 - 8,7.5 - 9,7.5 - 12,7.1
1 - 24
dr.06 DASM stator resistance 0606h appl P E 0.000 250.000 LTK 0.001 Ohm
6.2 - 5,6.2 - 7,6.2 - 10,6.2 - 1
1,6.2 - 14,6.2 - 15,7.5 - 8,7.5
- 9,7.5 - 14,7.5 - 16,7.11 - 24
dr.07 DASM leakage inductance 0607h appl P --- 0.01 655.35 LTK 0.01 mH
6.2-10, 6.2-14, 7.5-16, 7.5-
19, 7.5-24, 7.5-27, 7.11-24
dr.08 DASM rotor resistance 0608h appl P --- 0.000 250.000 LTK 0.001 Ohm
6.2-10, 6.2-14, 7.5-4, 7.5-
16, 7.5-19
dr.09 breakdown factor 0609h appl P --- 0.5 4.0 2.5 0.1 --- 7.5-8, 7.5-9, 7.5-10
dr.10 DASM head-inductance 060Ah appl P --- 0.1 3276.7 LTK 0.1 mH
6.2-7, 6.2-10, 6.2-11, 6.2-
14, 6.2-15, 7.5-14, 7.5-16
dr.11 motorprotection mode 060Bh appl P --- 0 1 1 1 --- 7.13-27
dr.12 motorprot. rated current 060Ch appl P --- 0.0 1100.0 LTK 0.1 A 7.13-26, 7.13-27
dr.13 DASM magnetizing current 060Dh appl P --- 0.0 1100.0 0.0 0.1 A
dr.14 DASM rated torque 060Eh RO P --- 0.01 32000.00 0.01 Motdat 0.01 Nm 7.2-13, 7.5-26, 7.8-4
dr.15 max. torque FU 060Fh RO P --- 0.01 32000.00 0.01 Motdat 0.01 Nm
7.8-5, 7.8-6, 7.8-7,
7.8-15, 7.9-3, 7.13-29
dr.16 DASM Mmax at dr.18 0610h appl P --- 0.01 32000.00 0.01 Adpt 0.01 Nm
7.5 - 12,7.5 - 25,7.5 - 26,7.8
- 5,7.8 - 6,7.13 - 13,7.13 - 20
dr.17 DASM speed for max. torque 0611h appl P --- 1 ; 0.125 64000 ; 8000
900 ; 112.5
Adpt
1 ;
0.125
rpm
5.1-4, 6.2-11, 6.2-15, 7.5-
13, 7.5-17, 7.5-18, 7.5-20,
7.5-22
dr.18 DASM eld weak speed 0612h appl P --- 0 64000 ; 8000 0 Adpt
1 ;
0.125
rpm
5.1 - 4,6.2 - 10,6.2 - 14,7.5
- 12,7.5 - 15,7.5 - 23,7.5 - 2
5,7.5 - 37,7.8 - 5,7.8 - 6,7.8
- 15
dr.19 ux adaption factor 0613h appl P --- 25 250 100 Adpt 1 %
7.5 - 12,7.5 - 15,7.5 - 16,7.5
- 19,7.5 - 23
dr.20 eld weak. curve 0614h appl P --- 0.01 2.00 1.20 Adpt 0.01 --- 7.5-12, 7.5-15, 7.5-37
dr.21 no load voltage 0615h appl P --- 0.0 100.0 75.0 0.1 %
dr.23 DSM rated current 0617h appl np --- 0.0 1100.0 LTK 0.1 A
6.2 - 18,6.2 - 19,7.6 - 3,7.6 -
6,7.6 - 10,7.11 - 24,7.13 - 30
dr.24 DSM rated speed 0618h appl np --- 0 64000 ; 8000 LTK
1 ;
0.125
rpm
5.1 - 4,6.2 - 18,6.2 - 19,7.6 -
3,7.6 - 17,7.11 - 24,7.13 - 30
dr.24 DSM rated speed 0618h appl np --- 0 32000 ; 4000 LTK
1 ;
0.125
rpm
dr.25 DSM rated frequency 0619h appl np --- 0.0 1600.0 LTK 0.1 Hz
6.2-18, 6.2-19, 7.6-3, 7.11-
24
dr.26 DSM EMC [Vpk*1000RPM] 061Ah appl np --- 0 32000 LTK 1 ---
6.2-18, 6.2-19, 7.6-3, 7.6-
4, 7.6-11, 7.8-7, 7.11-24
dr.27 DSM rated torque 061Bh appl np --- 0.1 ; 1 6553.5 ; 65535 LTK 0.1 ; 1 Nm
5.1-4, 6.2-18, 6.2-19, 6.2-
20, 7.2-13, 7.6-3, 7.8-2,
7.8-7, 7.8-9, 7.8-10, 7.11-
24
dr.28 DSM curr. f. zero speed 061Ch appl np --- 0.0 1090.0 LTK 0.1 A
6.2-18, 6.2-19, 7.6-3, 7.6-
4, 7.11-24, 7.13-30
dr.30
DSM motor winding resi-
stance
061Eh appl np --- 0.000 250.000 LTK 0.001 Ohm
6.2-18, 6.2-19, 7.6-3, 7.6-
11, 7.11-24
dr.31
DSM motor winding in-
ductance
061Fh appl np --- 0.01 500.00 LTK 0.01 mH
6.2-18, 6.2-19, 7.6-3, 7.6-
10, 7.11-24
dr.32 DSM rated power 0620h RO np --- 0.01 1000.00 LTK 0.01 kW
7.2-13, 7.8-9, 7.8-10, 7.11-
24
further on next side
