KEB COMBIVERT F5-H User Manual

Page 11.1 - 10 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Parameter
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
dr.33 DSM max. torque 0621h appl np --- 0.1 ; 1 6553.5 ; 65535 LTK 0.1 ; 1 Nm
5.1-4, 6.2-18,6.2-20, 7.6-5,
7.6-22, 7.8-9, 7.8-10, 7.11-
24, 7.13-29
dr.34 mot. prot. time min. Is/Id 0622h appl np --- 0.1 25.5 8.0 0.1 s
7.13-29
dr.34 mot. prot. time min. Is/Id 0622h appl np --- 0.1 10.0 0.5 0.1 s
dr.35 mot. prot. time Imax 0623h appl np --- 0.1 10.0 0.2 0.1 s 7.13-29
dr.36 mot. prot. recovery time 0624h appl np --- 0.1 300.0 5.0 0.1 s 7.13-30
dr.37 max. current 0625h appl np --- 0.0 1100.0 LTK 0.1 A
7.5-27, 7.8-12, 7.8-14,
7.10-4, 7.15-5
dr.39 DSM corner speed 1 0627h appl np --- 0 64000 ; 8000
32000 ;
4000
1 ;
0.125
rpm 5.1-4, 7.6-25, 7.8-9, 7.8-10
dr.40 DSM corn. max. torque 2 0628h appl np --- 0.1 ; 1 6553.5 ; 65535 0.1 ; 1 0.1 ; 1 Nm 5.1-4, 7.6-25, 7.8-10
dr.41 DSM corner speed 1 2 0629h appl np --- 0 64000 ; 8000
32000 ;
4000
1 ;
0.125
rpm 5.1-4, 7.6-25, 7.8-10
dr.42 DSM corner max. torque 3 062Ah appl np --- 0.1 ; 1 6553.5 ; 65535 0.1 ; 1
0.1 ; 1 Nm 5.1-4, 7.6-22, 7.8-10
dr.43 DSM corner speed 1 3 062Bh appl np --- 0 64000 ; 8000
32000 ;
4000
1 ;
0.125
rpm 5.1-4, 7.6-22, 7.8-10
dr.44 DSM corn. max. torque 4 062Ch appl np --- 0.1 ; 1 6553.5 ; 65535 0.1 ; 1 0.1 ; 1 Nm 5.1-4, 7.6-22, 7.8-10
dr.45 DSM corner speed 1 4 062Dh appl np --- 0 64000 ; 8000
32000 ;
4000
1 ;
0.125
rpm 5.1-4, 7.6-22, 7.8-10
dr.46 DSM corner max. torque 5 062Eh appl np --- 0.1 ; 1 6553.5 ; 65535 0.1 ; 1 0.1 ; 1 Nm 5.1-4, 7.6-22, 7.8-10
dr.47 DSM corner speed 1 5 062Fh appl np --- 0 64000 ; 8000
32000 ;
4000
1 ;
0.125
rpm 5.1-4, 7.8-10
dr.48 motor identication 0630h appl np E 0 255 0 1 ---
6.2 - 11,6.2 - 15,6.2 - 18,6.2
- 19,7.5 - 16,7.5 - 17,7.5 - 18
,7.5 - 19,7.5 - 20,7.5 - 21,7.5
- 22,7.5 - 23,7.6 - 8,7.6 - 9,7.
6 - 10,7.6 - 11,7.6 - 12
dr.49 Lh ident. acc/dec time 0631h appl np --- 0.00 300.00 5.00 0.01 s
5.1-5, 6.2-11, 6.2-15, 7.5-
17, 7.5-20, 7.5-21, 7.6-11,
7.6-12
dr.50 mot. prot. min. Is/Id 0632h appl np --- 100 500 150 1 % 7.13-29, 7.13-30
dr.51 motortemp.for Rs corr. 0633h appl np --- 0 200 20 1 degree 7.3-21
dr.52 temperature coefcient 0634h appl np --- 0.0: off 25.0 0.0: off 0.1 ---
dr.53 Rs corr. delta temp. 0635h appl np --- 0: off 200 0: off 1 degree
dr.54 Rs corr. warning time 0636h appl np --- 240 16000 4000 1 s
dr.55 Rs corr. cooling time 0637h appl np --- 240 16000 4000 1 s
dr.56 Rs corr. max. temp. 0638h appl np --- 30 200 90 1 degree
dr.58 torque offset selector 063Ah appl np E 0 79 0 1 --- 7.5-21, 7.6-12
dr.59 torque offset 063Bh appl np --- -320.00 320.00 0.00 0.01 Nm 7.5-21, 7.6-12
dr.60 Rs corr auto temp. mode 063Ch appl np --- 0: off 1: on 0: off 1 ---
dr.61 Rs corr auto temp in.sel. 063Dh appl np E
0 4095 0 1 --- 7.3-10, 7.3-12
dr.62 state motor ident. 063Eh RO np --- 0 255 0 1 ---
6.2-11, 6.2-15, 7.5-17, 7.6-
9
dr.63
DSM EMC HR
(Vpk/1000rpm)
063Fh appl np --- 0 255.996 0 0.004 --- 7.6-3, 7.6-4, 7.6-11
dr.64
DSM winding inductance ma-
ximum
0640h appl np --- 0.01 500.00 LTK 0.01 mH 7.6-3
dr.65
DASM head inductance 50%
ux
0641h appl P --- 99 305 99 0.006 %
dr.66 motor identication error 0642h RO np --- 0 255 0 1 ---
dr.67
current for Ls/loff identica-
tion
0643h appl np --- 10 250 100 1 %
dS.00 Kp current 1100h appl P --- 0 32767 1500 Adpt 1 --- 7.5-12, 7.6-5, 7.10-3
dS.01 Ki current 1101h appl np --- 0 32767 1500 Adpt 1 --- 7.5-12, 7.6-5, 7.10-3
dS.02 current decoupling 1102h appl np E 0: off 2 0: off 1 --- 6.2-11, 6.2-15, 6.2-18,
6.2-20, 7.10-3
dS.02 current decoupling 1102h appl np E 0: off 1 0: off 1 ---
dS.03 curr./torq. mode 1103h
appl np E 0 63 0 1 ---
7.5-25, 7.8-5, 7.8-10, 7.8-
11, 7.8-12, 7.8-13, 7.10-3,
7.10-4, 7.15-5
dS.04 ux/rotor adaption mode 1104h appl P E 0 4095 0 1 ---
6.2-7, 6.2-10, 6.2-14, 7.5-
16, 7.5-22, 7.5-23, 7.5-25,
7.5-33, 7.5-37, 7.8-3, 7.15-
5, 7.15-16
dS.07 KI rotor adaption 1107h appl P --- 0 32767 1000 1 ---
further on next side
