Page 11.1 - 12 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Parameter
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
Ec.15 gear 2 determinator 100Fh appl np --- 1 32000 1000 1 ---
7.11 - 14,7.12 - 14,7.12 - 17,
7.12 - 18,7.12 - 24,7.12 - 26,
7.12 - 31
Ec.16 enc. 2 rotation 1010h appl np E 0 19 0 1 --- 7.11-12
Ec.17 enc.2 trigger 1011h appl np E 0 13 GBK 1 ---
7.11 - 13,7.12 - 30,7.12 - 31
Ec.20 enc. 2 operating mode 1014h appl np --- 0 3 GBK 1 ---
7.11 - 7,7.11 - 10,7.12 - 15,7
.12 - 16
Ec.21 SSI multiturn resolution 1015h appl np E 0 13 12 1 --- 7.11-19, 7.12-31
Ec.22 SSI clock frq. sel. 1016h appl np --- 0 1 0 1 --- 7.11-19
Ec.23 SSI data code 1017h appl np --- 0 1 1 1 --- 7.11-19
Ec.24 SSI power failure bit 1018h appl np --- 0: off 1: on 0: off 1 --- 7.11-19
Ec.25 nominal tacho speed 1019h appl np --- 1 16000 ; 2000 1500 ; 187.5
1 ;
0.125
rpm 5.1-4, 7.11-20
Ec.27 operation mode output 101Bh appl np E 0 127 0 1 --- 7.11-10, 7.11-16, 7.11-17
Ec.28 position ch2 over bus 101Ch appl np --- -2147483648 2147483647 0 1 inc 7.11-10, 7.11-13
Ec.29 position ch1 direct 101Dh RO np --- -2147483648 2147483647 0 1 inc
Ec.30 position ch2 direct 101Eh RO np --- -2147483648 2147483647 0 1 inc
Ec.31 position ch1 101Fh RO np --- -2147483648 2147483647 0 1 inc 7.3-12
Ec.32 position ch2 1020h RO np --- -2147483648 2147483647 0 1 inc 7.3-12
Ec.33 system offset ch1 1021h
appl np E -2147483648 2147483647 0 1 inc 7.11-18
Ec.34 system offset ch2 1022h appl np E -2147483648 2147483647 0 1 inc 7.11-18
Ec.36 enc. 1 encoder type 1024h RO np --- GBK GBK GBK 1 --- 7.11-21
Ec.37 enc. 1 encoder status 1025h RO np --- 0 255 0 1 ---
7.11-21, 7.11-22, 7.11-24,
7.11-25
Ec.38 enc. 1 encoder r/w 1026h
appl
(rd)
sup
(st)
np E 0 30 4 1 ---
7.11-21, 7.11-23, 7.11-24,
7.11-25, 7.12-14
Ec.38 enc. 1 encoder r/w 1026h
appl
(rd)
sup
(st)
np E 0 62 4 1 ---
Ec.39 enc. 1 over transmission 1027h appl np E 0 5 0 1 --- 7.11-4, 7.11-15,
7.11-25, 7.12-33, 7.12-34
Ec.39 enc. 1 over transmission 1027h appl np E 0 4 0 1 ---
Ec.40 act. absolute pos. el. 1028h RO np --- 0 65535 0 1 --- 7.5-34, 7.5-35
Ec.41 mode disp. multiturn 1029h appl np E 0 15 0 1 --- 7.11-20
Ec.42 enc. alarm mode 102Ah appl np --- 0 15 0 1
---
7.4-14, 7.11-7, 7.11-8
Ec.42 enc. alarm mode 102Ah appl np --- 0 15 1 1 ---
Ec.43 SSI data code channel 1 102Bh appl np E 0 1 0 1 --- 7.11-19
Ec.44 abs. Res. channel 1 102Ch appl np E 0 13 10 1 ---
Ec.45 UVW commutation per res. 102Dh appl np E 0 127 0 1 ---
Ec.46 PT1 time channel 1 102Eh appl np --- 0 256 0 1 ms 7.12-34
Ec.47 PT1 time channel 2 102Fh appl np --- 0 256 0 1 ms 7.12-34
Ec.48
scan channel 2 input selec-
tion
1030h appl np E 0 4095 0 1 --- 7.3-10
Ec.49
scan channel 1+ channel 2
input selection
1031h appl np E 0 4095 0 1 --- 7.3-10
Ec.50 scan position Ec.60 1032h RO np --- -2^31 2^31-1 0 1 inc 7.3-12
Ec.51 scan position Ec.61 1033h RO np --- -2^31 2^31-1 0 1 inc 7.3-12
Ec.53
encoder 1 SSI multiturn reso-
lution
1035h appl np E 0 13 0 1
--- 7.11-18, 7.12-33
Ec.54 encoder 1 SSI mode 1036h appl np E 0 3 0 1 --- 7.11-19
Ec.55 encoder 2 SSI mode 1037h appl np E 0 2 0 1 --- 7.11-20
Ec.56 gear 1 numerator 1038h appl np --- -2^30 2^30-1 0 1 --- 7.11-14
Ec.57 gear 1 denominator (long) 1039h appl np --- 1 2^30-1 1000 1 --- 7.11-14
Ec.58 gear 2 numerator 103Ah appl np --- -2^30 2^30-1 0 1 ---
7.11 - 13,7.11 - 14,7.12 - 24
Ec.59 gear 2 denominator (long) 103Bh appl np --- 1 2^30-1 1000 1 --- 7.11-14
Ec.60 system position channel 1 103Ch RO np --- -2^31 2^31-1 0 1 inc
Ec.61 system position channel 2 103Dh RO np --- -2^31 2^31-1 0 1 inc
Ec.63 encoder 2 over gear 103Fh appl np E 0 1 0 1 ---
Fr.01 copy parameter set 0901h appl P E -9 7 0 1 ---
6.2 - 4,6.2 - 6,6.2 - 9,6.2 - 13
,6.2 - 17,6.2 - 19,7.6 - 11,7.
6 - 12
Fr.02 parameter set source 0902h appl np E 0 5 0 1 --- 10.1 - 10
Fr.03 parameter set lock 0903h appl np E 0 255 0 1 --- 7.13-9
Fr.04 parameter set setting 0904h appl np E 0 7 0 1 ---
Fr.05 set activation delay 0905h appl P --- 0.00 32.00 0.00 0.01 s
further on next side
