Parameter
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 11.1 - 13
10
11
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
Fr.06 set deactivation delay 0906h appl P --- 0.00 32.00 0.00 0.01 s
Fr.07 paraset input selection 0907h appl np E 0 4095 0 1 --- 7.3-10, 7.3-11
Fr.08 motor set classication 0908h appl P E 0 7 0 1 --- 7.13-28, 7.13-29
Fr.09 bus parameter set 0909h appl np --- -1: act set 7 0 1 ---
Fr.10 load mot. dependent para. 090Ah appl P E 1 3 1 1 ---
6.2 - 5,6.2 - 7,6.2 - 10,6.2 - 1
, 4,6.2 - 18,6.2 - 19,7.5 - 9,7.
5 - 12,7.5 - 13,7.5 - 22,7.5 - 2
9,7.6 - 5,7.6 - 12,7.6 - 13,7.6
- 17,7.7 - 3,7.10 - 3,7.11 - 25
Fr.10 load mot. dependent para. 090Ah appl np E 1 2 1 1 ---
Fr.11 reset set input sel. 090Bh appl np E 0 4095 0 1 --- 7.3-10, 7.3-11
Fr.12 set change mode mod. on 090Ch appl np E 0 3 2 1 ---
Fr.12 set change mode mod. on 090Ch appl np E 0 3 0 1 ---
In.00 inverter type 0E00h RO np --- 0 65535 0 1 hex 7.1-4, 7.1-16
In.01 rated inverter current 0E01h RO np --- LTK LTK LTK 0.1 A
7.2 - 13,7.13 - 14,7.13 - 19,7
.13 - 25
In.03 max. carrier frequency 0E03h RO np --- 0 4 LTK 1 ---
7.1-4, 7.1-16, 7.10-2, 7.10-
5
In.04 rated carrier frequency 0E04h RO np --- 0 LTK LTK 1 ---
7.1-4, 7.1-16, 7.10-2, 7.10-
5
In.06 software version 0E06h RO np --- SW SW SW 0.01 --- 7.1-4, 7.1-16
In.07 software date 0E07h RO np --- SW SW SW 0.1 --- 7.1-4, 7.1-17
In.10 serial no. (date) 0E0Ah sup np --- 0 65535 0 1 --- 7.1-4, 7.1-17
In. 11 serial no. (count) 0E0Bh sup np --- 0 65535 0 1 --- 7.1-4, 7.1-17
In.12 serial no. (AB-no. high) 0E0Ch sup np --- 0 65535 0 1 --- 7.1-4, 7.1-17
In.13 serial no. (AB-no. low) 0E0Dh sup np --- 0 65535 0 1 --- 7.1-4, 7.1-17
In.14 customer no. high 0E0Eh sup np --- 0 65535 0 1 --- 7.1-4, 7.1-17
In.15 customer no. low 0E0Fh sup np --- 0 65535 0 1 --- 7.1-4, 7.1-17
In.16 QS no. 0E10h sup np --- 0 65535 0 1 --- 7.1-4, 7.1-17
In. 17 temp.- mode 0E11h RO np --- LTK LTK LTK 1 hex 7.1-4, 7.1-17
In.18 hardware current inverter 0E12h RO np --- LTK LTK LTK 0.1 A
7.5-17, 7.6-8, 7.6-17, 7.8-
4, 7.8-7, 7.10-4
In.20 KEB service slector 0E14h sup np E 0 39 0 1 --- 7.5-32, 7.16-12
In.21 KEB service data 0E15h sup np --- KEB serv. dataKEB serv. data
KEB serv.
data
1 --- 7.5-32
In.22 user parameter 1 0E16h appl np --- 0 65535 0 1 --- 7.1-4, 7.1-18
In.23 user parameter 2 0E17h appl np --- 0 65535 0 1 --- 7.1-4, 7.1-18
In. 24 last error 0E18h sup P E 0 255 0 1 --- 7.1-4, 7.1-18
In. 25 error assistance 0E19h RO P --- 0 65535 0 1 hex 7.1-4, 7.1-18
In.26 E.OC error counter 0E1Ah sup np --- 0 65535 0 1 --- 7.1-4, 7.1-18
In.27 E.OL error counter 0E1Bh sup np --- 0 65535 0 1 --- 7.1-4, 7.1-18
In.28 E.OP error counter 0E1Ch sup np --- 0 65535 0 1 --- 7.1-4, 7.1-18
In.29 E.OH error counter 0E1Dh sup np --- 0 65535 0 1 --- 7.1-4, 7.1-18
In.30 E.OHI error counter 0E1Eh sup np --- 0 65535 0 1 --- 7.1-4, 7.1-18
In.31 KEB-Hiperface 0E1Fh RO np --- 0 65535 GBK 1 --- 7.1-4, 7.1-18
In.32 interface software date 0E20h RO np --- 0 6553.5 GBK 0.1 --- 7.1-4, 7.1-18
In.33 interface software version 0E21h RO np --- 0 655.35 GBK 0.01 --- 7.1-19
In.34 LTK data Id 0E22h sup np E 0 20 0 1 ---
In.35 LTK data index 0E23h sup np --- -1 LTK data Id -1 1 ---
In.36 LTK value index 0E24h sup np E 0 LTK 0 1 ---
In.37 LTK data 0E25h RO np --- 0 65535 0 1 ---
In.39 deadtime selector 0E27h appl np E 0 329 0 1 --- 7.6-11
In.40 deadtime 0E28h appl np --- 0 255 0 1 --- 7.6-11
LE.00 comparison level 0 0D00h appl P ---
-10737418.24 10737418.23 0.00 0.01 ---
7.3-22, 7.12-75, 7.15-76,
7.15-9, 7.15-12, 7.15-22
LE.01 comparison level 1 0D01h appl P --- -10737418.24 10737418.23 0.00 0.01 --- 7.3-26, 7.12-49
LE.02 comparison level 2 0D02h appl P --- -10737418.24 10737418.23 100.00 0.01 --- 7.3-26, 7.12-49
LE.03 comparison level 3 0D03h appl P --- -10737418.24 10737418.23 4.00 0.01 --- 7.12-49
LE.04 comparison level 4 0D04h appl P --- -10737418.24 10737418.23 0.00 0.01 --- 7.5-26
LE.05 comparison level 5 0D05h appl P --- -10737418.24 10737418.23 0.00 0.01 ---
LE.06 comparison level 6 0D06h appl P --- -10737418.24 10737418.23 0.00 0.01 ---
LE.07 comparison level 7 0D07h appl P --- -10737418.24 10737418.23 0.00 0.01 ---
7.3 - 22,7.12 - 75,7.12 - 76,7
.15 - 12
LE.08 hysteresis 0 0D08h appl P --- 0.00 300.00 0.00 0.01 --- 7.3-22
LE.09 hysteresis 1 0D09h appl P --- 0.00 300.00 0.00 0.01 --- 7.3-22, 7.3-26
LE.10 hysteresis 2 0D0Ah appl P --- 0.00 300.00 5.00 0.01 --- 7.3-26
LE.11 hysteresis 3 0D0Bh appl P --- 0.00 300.00 0.50 0.01 ---
LE.12 hysteresis 4 0D0Ch appl P --- 0.00 300.00 0.00 0.01 --- 7.5-26
LE.13 hysteresis 5 0D0Dh appl P --- 0.00 300.00 0.00 0.01 ---
LE.14 hysteresis 6 0D0Eh appl P --- 0.00 300.00 0.00 0.01 ---
further on next side
