KEB COMBIVERT F5-H User Manual

Page 11.1 - 14 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Parameter
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
LE.15 hysteresis 7 0D0Fh appl P --- 0.00 300.00 0.00 0.01 --- 7.3-22
LE.16 freq/speed hysteresis 0D10h appl np --- 0 n * 200 n * 15
n *
0.125
rpm
7.3 - 18,7.3 - 22,7.13 - 41,7.
15 - 4,10.1 - 12
LE.17 timer 1 start inp. sel. 0D11h appl np E 0 4095 0 1 ---
7.1 - 11,7.3 - 10,7.3 - 11,7.1
5 - 9,7.15 - 10,7.15 - 11
LE.18 timer 1 start condition 0D12h appl np E 0 15 0 1 --- 7.15-9, 7.15-10, 7.15-11
LE.19 timer 1 start inp. sel. 0D13h appl np E 0 4095 0 1 ---
7.3 - 10,7.3 - 11,7.12 - 50,7.1
5 - 9,7.15 - 11
LE.20 timer 1 reset condition 0D14h appl np E 0 31 16 1 --- 7.15-9, 7.15-11
LE.21 timer 1 mode 0D15h appl np --- 0 63 0 1 ---
7.1 - 11,7.15 - 9,7.15 - 10,7.1
5 - 11,7.15 - 12
LE.22 timer 2 start inp. sel. 0D16h appl np E 0 4095 0 1 ---
7.1 - 11,7.3 - 10,7.3 - 11,7.1
5 - 9,7.15 - 10,7.15 - 11
LE.23 timer 2 start condition 0D17h appl np E 0 15 0 1 --- 7.15-9, 7.15-10
LE.24 timer 2 start inp. sel. 0D18h appl np E 0 4095 0 1 ---
7.3-10, 7.3-11, 7.15-9,
7.15-11
LE.25 timer 2 reset condition 0D19h appl np E 0 31 16 1 --- 7.15-9, 7.15-11
LE.26 timer 2 mode 0D1Ah appl np --- 0 63 0 1 --- 7.1-11, 7.15-9, 7.15-10
LE.27 reference torque 0D1Bh appl np --- 0.00 32000.00 0.00 0.01 Nm 7.8-15
nn.00 motor model select 1400h appl np E 0 32767 191 1 ---
7.6-3, 7.6-8, 7.6-11, 7.6-14,
7.6-16, 7.6-17, 7.6-18
nn.01
standstill current and stabili-
sation current
1401h appl np --- 0 1100.0 0 0.1 A
7.6-5, 7.6-13, 7.6-14, 7.6-
15, 7.6-16, 7.6-17
nn.02
minimum speed for current
1402h appl np --- 0 32000 ; 4000 0
1 ;
0.125
rpm
5.1-4, 7.6-5, 7.6-13, 7.6-
14, 7.6-15
nn.03
maximum speed for current
1403h appl np --- 0 32000 ; 4000 0
1 ;
0.125
rpm
5.1-4, 7.6-5, 7.6-13, 7.6-
14, 7.6-15
nn.04 time speed calculation 1404h appl np --- 0.000 4095.938 0.125 0.063 ms 7.6-17
nn.05 lter speed calculation 1405h appl np
--- 0.000 4095.938 1.000 0.063 ms 7.6-17
nn.06 RS adaption factor 1406h appl np --- 0 32767 100 1 --- 7.6-17
nn.07 observer factor 1407h appl np --- 0 60.00 2.00 0.0015 % 7.6-17
nn.08
start-up speed
1408h appl np --- 0 n * 4000 0
n *
0.125
rpm 5.1-4, 7.6-14, 7.6-15
nn.09 start-up time 1409h appl np --- 0.00 300.00 5.00 0.01 s 7.6-14
nn.10
standstill current
140Ah appl np --- 0 1100.0 0 0.1 A
7.6-5, 7.6-13, 7.6-16, 7.6-
17
nn.11 stabilisation time 140Bh appl np --- 0.000 4095.938 0.250 0.063 ms 7.6-5
nn.12 deviation control time 140Ch appl np --- 0.000 4095.938 10.000 0.063 ms 7.6-18
nn.13 C lter [uF] 140Dh appl np --- 0.00 655.35 0.00 0.01 --- 7.6-18
nn.14 amplitude HF injection 140Eh appl np --- 0 16383 1500 1 --- 7.6-21
nn.15 optimization HF injection 140Fh appl np E 20 15.0 4.0 0.1 --- 7.6-21
nn.17 open loop speed 1411h appl np
--- 0 n * 4000 0
n *
0.125
rpm 7.6-21
oP.00 reference source 0300h appl P E 0 10 0 1 ---
7.1-21, 7.4-2, 7.4-4, 7.4-5,
7.15-25, 7.15-29, 7.15-30,
7.15-31
oP.01 rotation source 0301h appl P E 0 11 7 1 ---
7.1-21, 7.4-2,
7.4-7, 7.4-8, 7.4-9, 7.4-10,
7.4-11, 7.12-4, 7.12-80
7.13-6, 10.1-10, 10.1-13
oP.02 rotation setting 0302h appl P E 0 2 0 1 --- 7.4-7, 7.4-8, 7.4-10
oP.03 dig. setpoint setting 0303h appl P --- n * -4000 n * 4000 0
n *
0.125
rpm
7.4 - 4,7.12 - 77,7.12 - 78,7.
12 - 79,7.12 - 80
oP.05 reference setting % 0305h appl P --- -100.0 100.0 0.0 0.1 % 7.2-10, 7.4-4
oP.06 min. reference forward 0306h appl P --- 0 n * 4000 0
n *
0.125
rpm
7.3-21, 7.4-4, 7.4-5, 7.4-
13, 7.4-15, 7.5-30, 7.13-24
oP.07 min. reference reverse 0307h appl P ---
n * -0.125:
=For
n * 4000
n * -0.125:
=For
n *
0.125
rpm
7.3-21, 7.4-4, 7.4-5, 7.4-
15, 7.5-30
oP.10 max. reference forward 030Ah appl P --- 0 n * 4000 n * 2100
n *
0.125
rpm
7.1 - 14,7.4 - 4,7.4 - 5,7.4 - 1
3,7.4 - 14,7.4 - 15,7.12 - 22,
7.12 - 28,7.12 - 29,7.12 - 35,
7.12 - 37,7.12 - 38,7.12 - 46,
7.12 - 48,7.13 - 24,7.15 - 27
further on next side
