KEB COMBIVERT F5-H User Manual

Parameter
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 11.1 - 15
10
11
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
oP.11 max. reference reverse 030Bh appl P ---
n * -0.125:
=For
n * 4000
n * -0.125:
=For
n *
0.125
rpm
7.4-4, 7.4-9, 7.4-13, 7.4-14,
7.4-15, 7.12-22, 7.12-28
oP.14 abs. max. reference for 030Eh appl P --- 0 n * 4000 n * 4000
n *
0.125
rpm
7.4 - 5,7.4 - 13,7.4 - 14,7.12
- 14,7.12 - 22,7.12 - 28,7.12
- 29,7.12 - 78,7.12 - 81
oP.15 abs. max. reference rev 030Fh appl P ---
n * -0.125:
=For
n * 4000
n * -0.125:
=For
n *
0.125
rpm
7.4 - 13,7.4 - 14,7.12 - 14,7.
12 - 22,7.12 - 28,7.12 - 78,7
.12 - 81
oP.16 rotation delay time 0310h appl np --- 0 1000 0 1 s 7.4-10
oP.18 step value rot. source 0312h appl P E 0 10 7 1 --- 7.4-11, 7.4-12
oP.19 step value input sel. 1 0313h appl np E 0 4095 16 1 ---
7.3-10, 7.3-11, 7.4-11, 7.4-
12
oP.20 step value input sel. 2 0314h appl np E 0 4095 32 1 ---
7.3-10, 7.3-11, 7.4-11, 7.4-
12
oP.21 step value 1 0315h appl P --- n * -4000 n * 4000 n * 100
n *
0.125
rpm 7.4-11, 7.4-12, 7.16-6
oP.22 step value 2 0316h appl P --- n * -4000 n * 4000 n * -100
n *
0.125
rpm 7.4-11
oP.23 Step value 3 0317h appl P --- n * -4000 n * 4000 n * 0
n *
0.125
rpm 7.4-11, 7.4-12
oP.27
acceleration/deceleration
mode
031Bh appl P E 0 511 0 1 --- 7.4-16, 7.4-20, 7.4-22
oP.28 acceleration time forward 031Ch appl P --- 0.00 300.00 5.00 0.01 s
7.4-17, 7.4-18, 7.4-20, 7.4-
22, 7.12-19, 7.16-6
oP.29 acc. time reverse 031Dh appl P --- -0.01: =For 300.00 -0.01: =For 0.01 s 7.4-17, 7.4-18
oP.30 deceleration time forward 031Eh appl P --- -0.01: =Acc
300.00 5.00 0.01 s
7.4-18, 7.4-20, 7.4-21,
7.16-6
oP.31 dec. time reverse 031Fh appl P --- -0.01: =For 300.00 -0.01: =For 0.01 s
7.4-17, 7.4-18, 7.4-20, 7.4-
21, 7.12-28
oP.32 s-curve time acc. for. 0320h appl P --- 0.00: off 5.00 0.00: off 0.01 s 7.4-17, 7.4-19, 7.12-28
oP.33 s-curve time acc. 0321h appl P --- -0.01: =For 5.00 -0.01: =For 0.01 s 7.4-19, 7.4-20
oP.34 s-curve time dec. for. 0322h appl P --- -0.01: =Acc 5.00 -0.01: =Acc 0.01 s 7.4-19, 7.4-20
oP.35 s-curve time dec. rev. 0323h appl P --- -0.01: =For 5.00 -0.01: =For 0.01 s 7.4-17, 7.4-19, 7.12-28
oP.40 max. output val. for. 0328h appl P --- 0 n * 4000 n * 4000
n *
0.125
rpm
7.4-14, 7.6-17, 7.12-28,
7.13-10, 7.13-24
oP.41 max. output val. rev. 0329h appl P ---
n * -0.125:
=For
n * 4000
n * -0.125:
=For
n *
0.125
rpm 7.4-14, 7.6-17, 7.13-10
oP.44 ext. function mode/source 032Ch appl P E 0 79 0 1 --- 7.15-19, 7.15-21
oP.45 ext. funct. dig. source 032Dh appl P --- 0.00 100.00 0.00 0.01 % 7.15-19, 7.15-21
oP.46 ext. funct. acc/dec time 032Eh appl P --- 0.00 20.00 10.00 0.01 s 7.15-19, 7.15-22
oP.47 sweep-gen. acc. time
032Fh appl P --- 0.00 20.00 10.00 0.01 s 7.15-19, 7.15-20
oP.48 sweep-gen. dec. time 0330h appl P --- 0.00 20.00 10.00 0.01 s 7.15-19, 7.15-20
oP.49 diam. corr. dmin/dmax 0331h appl P --- 0.010 0.990 0.500 0.001 --- 7.15-21
oP.50 motorpoti function 0332h appl np E 0 7 0 1 --- 7.1-11, 7.15-7, 7.15-8
oP.52 motorpoti value 0334h appl P --- -100.00 100.00 0.00 0.01 %
7.4-4, 7.11-16, 7.12-24,
7.15-7
oP.53 motorpoti min. value 0335h appl np --- -100.00 100.00 0.00 0.01 % 7.1-11, 7.11-16, 7.15-9
oP.54 motorpoti max. value 0336h appl np --- -100.00 100.00 100.00 0.01 % 7.11-16, 7.15-9
oP.55 motorpoti reset value 0337h appl np --- -100.00 100.00 0.00 0.01 % 7.15-7, 7.15-8
oP.56 mot.poti inc. input sel. 0338h appl np E 0 4095 0 1 --- 7.3-10, 7.3-11, 7.15-7
oP.57 mot.poti dec. input sel. 0339h appl np E 0 4095 0 1 --- 7.3-10, 7.3-11, 7.15-7
oP.58 mot.poti reset inp. sel. 033Ah appl np E 0 4095 0 1 ---
7.3-10, 7.3-11, 7.15-7,
7.15-8
oP.59
motorpoti increase/decrease
time
033Bh appl P --- 0.00 50000.00 66.00 0.01 s 7.1-11, 7.15-7, 7.15-8
oP.60 dir. forward input sel. 033Ch appl np E 0 4095 4 1 --- 7.3-10, 7.3-11, 7.4-8, 7.4-9
oP.61
direction reverse input selec-
tion
033Dh appl np E 0 4095 8 1 --- 7.3-10, 7.3-11, 7.4-8, 7.4-9
oP.62 acc/dec time factor 033Eh appl np E 0 4 0 1 --- 7.4-22
oP.63 ref. value high-res. 033Fh appl np --- -2^31 2^31-1 0 1 --- 7.4-4, 7.4-6, 7.4-7
oP.64 rel. value high-res. 0340h appl P --- n * 600 n * 4000 n * 2100
n *
0.125
rpm 7.4-4, 7.4-5, 7.4-6, 7.4-7
oP.65 min. proh. reference 1 0341h appl np --- n * -4000 n * 4000 0
n *
0.125
rpm 7.4-15, 7.5-30
oP.66 max. proh. reference 1 0342h appl np --- n * -4000 n * 4000 0
n *
0.125
rpm 7.4-15
further on next side
