KEB COMBIVERT F5-H User Manual

Page 11.1 - 16 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Parameter
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
oP.67 min. proh. reference 2 0343h appl np --- n * -4000 n * 4000 0
n *
0.125
rpm 7.4-15
oP.68 max. proh. reference 2 0344h appl np --- n * -4000 n * 4000 0
n *
0.125
rpm 7.4-15, 7.5-30
oP.69 motorpoti deceleration time 0345h appl P --- -0.01 50000.00 -0.01 0.01 s
oP.70 s-c. up time acc. for. 0346h appl P --- -0.01: = low 5.00 -0.01: = low 0.01 s
7.4-17, 7.4-19, 7.4-20,
7.12-28
oP.71 s-c. up time acc. rev. 0347h appl P --- -0.02: =For 5.00 -0.01: = low 0.01 s 7.4-19, 7.4-20
oP.72 s-c. up time dec. for. 0348h appl P --- -0.02: =Acc 5.00 -0.01: = low 0.01 s 7.4-19, 7.4-20
oP.73 s-c. up time dec. rev. 0349h appl P --- -0.02: =Acc 5.00 -0.01: = low 0.01 s
7.4-17, 7.4-19, 7.4-20,
7.12-28
oP.74 reference splitting 034Ah appl np --- 0 127 0 1 ms 7.7-10
Pd.00 PD Byte order 0100h appl np E 0 2 2 1 ---
Pd.01 PD0 Out Index 0101h appl P E 0 32767 0 1 ---
Pd.02 PD Out Subindex
0102h appl P E 8 1 1 1 ---
Pd.03 PD Out Offset 0103h appl P E 15 0 0 1 ---
Pd.04 PD Out Type 0104h appl P E 3 0 0 1 ---
Pd.05 PD Out Count 0105h appl np E 0 8 0 1 ---
Pd.06 PD0 In Index 0106h appl P E 0 32767 0 1 ---
Pd.07 PD0 In Subindex 0107h appl P E 1 8 1 1 ---
Pd.08 PD0 In Offset 0108h appl P E 0 15 0 1 ---
Pd.09 PD0 In Type 0109h appl P E 0 3 0 1 ---
Pd.10 PD0 In Count 010Ah appl np E 0 8 0 1 ---
Pd.11 PD1 Out Index 010Bh appl P E 0 32767 0 1 ---
Pd.12 PD1 Out Subindex 010Ch appl P E 1 8 1 1 ---
Pd.13 PD1 Out Offset 010Dh appl P E 0 15 0 1 ---
Pd.14 PD1 Out Type 010Eh appl
P E 0 3 0 1 ---
Pd.15 PD1 Out Count 010Fh appl np E 0 8 0 1 ---
Pd.16 PD1 In Index 0110h appl P E 0 32676 0 1 ---
Pd.17 PD1 In Subindex 0111h appl P E 1 8 1 1 ---
Pd.18 PD1 In Offset 0112h appl P E 0 15 0 1 ---
Pd.19 PD1 In Type 0113h appl P E 0 3 0 1 ---
Pd.20 PD1 In Count 0114h appl np E 0 8 0 1 ---
Pd.21 PD2 Out Index 0115h appl P E 0 32767 0 1 ---
Pd.22 PD2 Out Subindex 0116h appl P E 1 8 1 1 ---
Pd.23 PD2 Out Offset 0117h appl P E 0 15 0 1 ---
Pd.24 PD2 Out Type 0118h appl P E 0 3 0 1 ---
Pd.25 PD2 Out Count 0119h appl np E 0 8 0 1 ---
Pd.26 PD2 In Index 011Ah appl P E
0 32767 0 1 ---
Pd.27 PD2 In Subindex 011Bh appl P E 1 8 1 1 ---
Pd.28 PD2 In Offset 011Ch appl P E 0 15 0 1 ---
Pd.29 PD2 In Type 011Dh appl P E 0 3 0 1 ---
Pd.30 PD2 In Count 011Eh appl np E 0 8 0 1 ---
Pn.00 auto. retry UP 0400h appl np --- 0: off 1: on 1: on 1 --- 7.3-21, 7.13-16
Pn.01 auto. retry OP 0401h appl np --- 0: off 1: on 0: off 1 --- 7.13-16
Pn.02 auto. retry OC 0402h appl np --- 0: off 1: on 0: off 1 --- 7.13-17
Pn.03 E.EF stopping mode 0403h appl np --- 0 6 0 1 ---
7.13-7, 7.13-11, 7.13-12,
7.13-17
Pn.04 ext. fault input select 0404h appl np E 0 4095 64 1 ---
7.3-10, 7.3-11, 7.13-7,
7.13-40
Pn.05 E.buS stopping mode 0405h appl np --- 0 6 6 1 ---
7.12 - 78,7.12 - 80,7.13 - 4,7
.13 - 7,7.13 - 11,7.13 - 12,7.1
3 - 17,10.1 - 9,10.1 - 10
Pn.06 watchdog time 0406h appl np E 0.00: off 40.00 0.00: off 0.01 s
7.3-21, 7.12-80, 7.13-7,
10.1-9
Pn.07
prohibit rotation stopping
mode
0407h appl np --- 0 6 6 1 ---
7.12 - 4,7.12 - 9,7.12 - 29,7.
12 - 64,7.13 - 4,7.13 - 7,7.13
- 11,7.13 - 12,7.13 - 17
Pn.08 warning OL stop. mode 0408h appl np --- 0 6 6 1 ---
7.3 - 17,7.13 - 6,7.13 - 11,7.1
3 - 12,7.13 - 17
Pn.09 OL warning level 0409h appl np --- 0 100 80 1 % 7.3-17, 7.3-19, 7.13-6
Pn.10
warning OH stop. modeRes-
ponse
040Ah appl np --- 0 6 6 1 ---
7.3 - 17,7.13 - 4,7.13 - 6,7.1
3 - 11,7.13 - 12,7.13 - 17
Pn.11 OH warning level 040Bh appl np --- 0 90 70 1 degree 7.3-17, 7.13-4, 7.13-6
Pn.12
warning dOH stop. modeRe-
sponse
040Ch appl np --- 0 8 6 1 ---
7.1-17, 7.3-17, 7.13-8,
7.13-11, 7.13-12, 7.13-17
Pn.13 E.dOH delay time 040Dh appl np --- 0 120 0 1 s 7.1-17, 7.3-17, 7.13-8
further on next side
