Page 11.1 - 20 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Parameter
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
PS.16 limit switch right 1310h appl np --- -2^31 2^31-1 2^30-1 1 inc 7.13-8
PS.17 reference point 1311h appl np E -2^31 2^31-1 0 1 inc
7.3 - 12,7.12 - 7,7.12 - 10,7.
12 - 11,7.12 - 12,7.12 - 55,7.
12 - 56,7.12 - 75
PS.18
reference switch input selec-
tion
1312h appl np E 0 4095 0 1 --- 7.3-10, 7.3-11, 7.12-5
PS.19 start reference input selection 1313h appl np E 0 4095 0 1 ---
7.3-10, 7.3-11, 7.12-5,
7.12-6
PS.20 reference acc/dec time 1314h appl np --- 0.00 300.00 0.50 0.01 s
7.12-6, 7.12-7, 7.12-9,
7.12-10, 7.12-12
PS.21 reference speed 1315h appl np --- n * -4000 n * 4000 n * 100
n *
0.125
rpm
5.1-4, 7.12-6, 7.12-7, 7.12-
10
PS.22 reference drive free speed 1316h appl np --- 0: off n * 4000 0: off
n *
0.125
rpm
5.1-4, 7.12-6, 7.12-7, 7.12-
10
PS.23 index selection 1317h appl np E 0 31 0 1 ---
7.12 - 35,7.12 - 38,7.12 - 41,
7.12 - 42,7.12 - 44,7.12 - 45,
7.12 - 46,7.12 - 47,7.12 - 50,
7.12 - 51,7.12 - 62,7.12 - 64,
7.12 - 70,7.12 - 72,7.12 - 73
PS.24 index position 1318h appl np --- -2^31 2^31-1 0 1 inc
7.3 - 12,7.12 - 29,7.12 - 35,
7.12 - 36,7.12 - 38,7.12 - 39
,7.12 - 41,7.12 - 42,7.12 - 44
,7.12 - 45,7.12 - 46,7.12 - 47
,7.12 - 49,7.12 - 50,7.12 - 51
,7.12 - 52,7.12 - 54,7.12 - 55
,7.12 - 56,7.12 - 57,7.12 - 58
,7.12 - 62,7.12 - 63,7.12 - 64
,7.12 - 68,7.12 - 69,7.12 - 70
,7.12 - 71,7.12 - 73,7.12 - 74
,7.12 - 75,7.12 - 77,7.12 - 78
PS.25 index speed 1319h appl np E n * -4000 n * 4000 0
n *
0.125
rpm
5.1 - 4,7.12 - 12,7.12 - 28,7.
12 - 29,7.12 - 30,7.12 - 32,7
.12 - 35,7.12 - 36,7.12 - 37,7
.12 - 38,7.12 - 39,7.12 - 40,
7.12 - 41,7.12 - 42,7.12 - 43,
7.12 - 44,7.12 - 45,7.12 - 46,
7.12 - 47,7.12 - 48,7.12 - 50,
7.12 - 51,7.12 - 62,7.12 - 68
PS.26 next index 131Ah appl np E -1: PS.28 31 -1: PS.28 1 ---
7.3 - 19,7.12 - 35,7.12 - 38,7
.12 - 39,7.12 - 41,7.12 - 42,7
.12 - 44,7.12 - 45,7.12 - 47,7
.12 - 50,7.12 - 51,7.12 - 62,7
.12 - 75
PS.27 index mode 131Bh appl np E 0 31 0 1 ---
7.3 - 12,7.12 - 35,7.12 - 38,
7.12 - 39,7.12 - 40,7.12 - 41
,7.12 - 42,7.12 - 44,7.12 - 45
,7.12 - 47,7.12 - 50,7.12 - 51
,7.12 - 52,7.12 - 56,7.12 - 57
,7.12 - 58,7.12 - 62,7.12 - 74
PS.28 start index new prole 131Ch appl P E 0 31 0 1 ---
7.3 - 19,7.3 - 20,7.12 - 35,7.
12 - 39,7.12 - 40,7.12 - 41,7
.12 - 44,7.12 - 46,7.12 - 48,7
.12 - 51,7.12 - 62,7.12 - 63,
7.12 - 64,7.12 - 69,7.12 - 72,
7.12 - 75
PS.29 start posi input selection 131Dh appl np E 0 4095 0 1 ---
7.3 - 10,7.3 - 11,7.12 - 29,7.1
2 - 44,7.12 - 46,7.12 - 48,7.1
2 - 49,7.12 - 63
further on next side
