KEB COMBIVERT F5-H User Manual

Page 11.1 - 22 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Parameter
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
ru.00 inverter state 0200h RO np --- 0 255 0 1 --- 7.1-5
ru.01 set value display 0201h RO np --- n * -4000 n * 4000 0
n *
0.125
rpm
5.1 - 4,7.1 - 3,7.1 - 5,7.2 - 13,
7.3 - 18,7.4 - 3,7.4 - 21,7.5 -
22,7.13 - 41,7.15 - 4,7.15 - 1
4,7.15 - 15,7.15 - 30,7.15 - 3
1,10.1 - 12
ru.02 ramp output display 0202h RO np --- n * -4000 n * 4000 0
n *
0.125
rpm
5.1 - 4,7.1 - 3,7.1 - 5,7.2 - 13,7
.3 - 18,7.3 - 19,7.3 - 21,7.4 - 3,
7.4 - 21,7.5 - 34,7.5 - 35,7.6 -
13,7.9 - 4,7.12 - 7,7.12 - 10,7.
12 - 12,7.12 - 14,7.12 - 29,7.1
2 - 43,7.12 - 47,7.12 - 53,7.12
- 54,7.12 - 61,7.12 - 65,7.12 -
67,7.12 - 68,7.12 - 73,7.12 - 8
1,7.13 - 22,7.13 - 25,7.15 - 4,
7.15 - 21,7.15 - 27,7.15 - 28,7
.15 - 30,7.15 - 31,7.15 - 32
ru.03 actual frequency display 0203h RO np --- n * -400 n * 400 0
n *
0.0125
Hz
5.1 - 4,7.1 - 3,7.1 - 5,7.4 - 3,7
.5 - 4,7.5 - 5,7.5 - 29,7.5 - 34,
7.5 - 35,7.13 - 24,7.13 - 25,7
.15 - 4,7.15 - 5,7.15 - 28
ru.06 calculated actual value 0206h RO np --- n * -4000 n * 4000 0
n *
0.125
rpm 5.1-4
ru.07 actual value display 0207h RO np --- n * -4000 n * 4000 0
n *
0.125
rpm
5.1 - 4,7.1 - 3,7.1 - 6,7.1 - 1
4,7.2 - 10,7.2 - 13,7.3 - 18,
7.3 - 21,7.4 - 14,7.5 - 29,7.
5 - 34,7.5 - 35,7.6 - 15,7.6 -
17,7.11 - 17,7.13 - 10,7.13
- 41,7.15 - 5,10.1 - 12
ru.09 encoder 1 speed 0209h RO np --- n * -4000 n * 4000 0
n *
0.125
rpm
5.1-4, 7.1-3, 7.1-6, 7.2-10,
7.3-21, 7.6-6
ru.10 encoder 2 speed 020Ah RO np --- n * -4000 n * 4000 0
n *
0.125
rpm
5.1-4, 7.1-3, 7.1-6, 7.2-10,
7.3-21, 7.6-6, 7.12-14,
7.12-81
ru.11 set torque 020Bh RO np --- -32000.00 32000.00 0 0.01 Nm
7.1-3, 7.1-6, 7.1-14, 7.2-11,
7.8-14
ru.12 actual torque 020Ch RO np --- -32000.00 32000.00 0 0.01 Nm
7.1 - 3,7.1 - 6,7.1 - 14,7.2 - 1
1,7.5 - 21,7.5 - 29,7.5 - 30,7.
6 - 9,7.6 - 11,7.6 - 17,7.8 - 14
,7.8 - 16
ru.13 actual utilization 020Dh RO np --- 0 65535 0 1 %
7.1-3, 7.1-6, 7.3-18, 7.10-
5, 7.13-25, 7.15-29
ru.14 peak utilization 020Eh appl np --- 0 65535 0 1 % 7.1-3, 7.1-6
ru.15 apparent current 020Fh RO np --- 0 6553.5 0 0.1 A
7.1 - 3,7.1 - 6,7.2 - 11,7.2 - 1
3,7.3 - 19,7.5 - 29,7.10 - 5,7.
13 - 19,7.13 - 24,7.13 - 26,7.
13 - 27,7.13 - 29
ru.16 peak apparent current 0210h appl np --- 0 6553.5 0 0.1 A 7.1-3, 7.1-6
ru.17 active current 0211h RO np --- -3276.7 3276.7 0 0.1 A
7.1 - 3,7.1 - 6,7.2 - 11,7.2 - 13
,7.3 - 18,7.3 - 21,7.5 - 34,7.5
- 35,7.6 - 17,7.13 - 19,7.13 - 2
4,7.15 - 29,7.15 - 31,7.15 - 32
ru.18 actual DC voltage 0212h RO np --- 0 1500 0 1 V
7.1 - 3,7.1 - 7,7.2 - 11,7.2 - 1
3,7.3 - 18,7.5 - 34,7.5 - 35,7.
13 - 23,7.13 - 26,7.15 - 29
ru.19 peak DC voltage 0213h appl np --- 0 1500 0 1 V 7.1-3, 7.1-7
ru.20 output voltage 0214h RO np --- 0 1167 0 1 V 7.1-3, 7.1-7, 7.2-11, 7.2-13
ru.21 input terminal state 0215h RO np --- 0 4095 0 1 --- 7.1-3, 7.1-7, 7.3-3, 7.3-5
further on next side
