KEB COMBIVERT F5-H User Manual

Parameter
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 11.1 - 23
10
11
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
ru.22 internal input state 0216h RO np --- 0 4095 0 1 ---
7.1-3, 7.1-7, 7.3-2, 7.3-3,
7.3-5, 7.3-19, 7.3-20, 10.1-
13
ru.23 output condition state 0217h RO np --- 0 255 0 1 --- 7.1-3, 7.1-8, 7.3-15, 7.3-16
ru.24 state of output ags 0-7 0218h RO np --- 0 255 0 1 --- 7.1-3, 7.1-8, 7.3-15, 7.3-16
ru.25 output terminal state 0219h RO np --- 0 255 0 1 ---
7.1 - 3,7.1 - 9,7.3 - 15,7.3 - 1
6,7.3 - 25,10.1 - 13
ru.26 active parameter set 021Ah RO np --- 0 7 0 1 ---
7.1 - 3,7.1 - 9,7.13 - 29,7.1
5 - 8
ru.27 AN1 pre amplier disp. 021Bh RO np --- -100.0 100.0 0 0.1 %
7.1 - 3,7.1 - 9,7.2 - 3,7.2 - 11,
7.2 - 13,7.15 - 30,7.15 - 31,7
.15 - 32
ru.28 AN1 post amplier disp. 021Ch RO np --- -400.0 400.0 0 0.1 %
7.1 - 3,7.1 - 9,7.2 - 3,7.2 - 10,
7.2 - 11,7.2 - 13,7.15 - 19,7.1
5 - 21,7.15 - 28,7.15 - 29,7.1
5 - 30,7.15 - 31,7.15 - 32
ru.29 AN2 pre amplier disp. 021Dh RO np --- -100.0 100.0 0 0.1 %
7.1 - 3,7.1 - 9,7.2 - 3,7.2 - 11,
7.2 - 13,7.15 - 30,7.15 - 31,7
.15 - 32
ru.30 AN2 post amplier disp. 021Eh RO np --- -400.0 400.0 0 0.1 %
7.1 - 3,7.1 - 10,7.2 - 3,7.2 - 1
0,7.2 - 11,7.2 - 13,7.15 - 19,
7.15 - 21,7.15 - 28,7.15 - 29,
7.15 - 30,7.15 - 31,7.15 - 32
ru.31 AN3 pre amplier disp. 021Fh RO np --- -100.0 100.0 0 0.1 % 7.1-3, 7.1-10, 7.2-3
ru.32 AN3 post amplier disp. 0220h RO np --- -400.0 400.0 0 0.1 %
7.1 - 3,7.1 - 10,7.2 - 3,7.2 - 1
0,7.15 - 19,7.15 - 21,7.15 - 2
8,7.15 - 29
ru.33 ANOUT1 pre ampl. disp. 0221h RO np --- -400.0 400.0 0 0.1 % 7.1-3, 7.1-10, 7.2-12
ru.34 ANOUT1 post ampl. disp. 0222h RO np --- -115.0 115.0 0 0.1 %
7.1-3, 7.1-10, 7.2-10, 7.2-
12, 7.3-20
ru.35 ANOUT2 pre ampl. disp. 0223h RO np --- -400.0 400.0 0 0.1 % 7.1-3, 7.1-10, 7.2-12
ru.36 ANOUT2 post ampl. disp. 0224h RO np --- -115.0 115.0 0 0.1 %
7.1-3, 7.1-10, 7.2-10, 7.3-
20
ru.37 motorpoti actual value 0225h RO np --- -100.00 100.00 0 0.01 %
7.1 - 3,7.1 - 11,7.2 - 10,7.4 -
4,7.8 - 13,7.9 - 3,7.11 - 16,7.
15 - 7,7.15 - 9
ru.38 power module temperature 0226h RO np --- 0 150 0 1 degree
7.1-3, 7.1-11, 7.2-11, 7.2-
13, 7.3-19
ru.39 OL counter display 0227h RO np --- 0 100 0 1 %
7.1-3, 7.1-11, 7.3-17, 7.13-
6
ru.40 power on counter 0228h sup np --- 0 65535 0 1 h 7.1-3, 7.1-11
ru.41 modulation on counter 0229h sup np --- 0 ru.40 0 1 h 7.1-3, 7.1-11
ru.42 modulation grade 022Ah RO np --- 0 110 0 1 %
6.2 - 7,7.1 - 3,7.1 - 11,7.5 - 4,
7.5 - 5,7.5 - 15,7.5 - 23,7.8 -
9,7.13 - 17
ru.43 timer 1 display 022Bh appl np --- 0 655.35 0 0.01 ---
7.1 - 3,7.1 - 11,7.3 - 18,7.12
- 50,7.15 - 9,7.15 - 11,7.15
- 12
ru.44 timer 2 display 022Ch appl np --- 0 655.35 0 0.01 ---
7.1 - 3,7.1 - 11,7.3 - 18,7.15
- 9,7.15 - 11,7.15 - 12
ru.45 act. switching frequency 022Dh RO np --- 0 4 0 1 --- 7.1-3, 7.1-12, 7.10-5
ru.46 motor temperature 022Eh RO np --- 0 255 0 1 degree
7.1 - 3,7.1 - 12,7.1 - 17,7.2 -
11,7.2 - 13,7.3 - 19,7.13 - 17
,7.13 - 18
ru.47 actual torque limit motor 022Fh RO np --- -32000.00 32000.00 0 0.01 Nm 7.1-3, 7.1-12, 7.8-14
ru.48 actual torque limit generator 0230h RO np --- -32000.00 32000.00 0 0.01 Nm 7.1-3, 7.1-12, 7.8-14
ru.49 actual reference torque 0231h RO np --- -32000.00 32000.00 0 0.01 Nm 7.1-3, 7.1-12
ru.51 power module temperature 0233h RO np --- -40 120 0 1 °C 7.1-3, 7.1-12,
ru.52 ext. PID out dislay 0234h RO np --- -400.0 400.0 0 0.1 %
7.1 - 3,7.1 - 12,7.2 - 10,7.2 -
11,7.2 - 13,7.4 - 4,7.15 - 26,
7.15 - 30,7.15 - 31,7.15 - 32
further on next side
