KEB COMBIVERT F5 MULTI User Manual

6
6
117
KEB COMBIVERT F5-M / S
Name: Basis
12.05.04
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
Functional DesriptionOperating and Unit Data
The AUX-input is adjusted with An.30. This parameter shows in percent the value of the analog singal AUX. The range of
display is limited to ±400 % (also see 6.2 ÑAnalog inputsì).
Adr.
min max
default
0234h
ru.52 External PID out display
0,1
%
-
100,0-100,0
A universal PID-controller is intergrated in the inverter. It can be used externally as well as internally. So that the
controller is as independent as possible, the displayed manipulated variable, referring to a +/- signal, is ouput in percent.
Adr.
min max
default
0235h
ru.53 AUX display
0,1
%
-
400,0-400,0
Adr.
min max
default
0231h
ru.49 Actual ref. torque
0,01
Nm
-
10000
-10000
This parameter displays the preadjusted setpoint torque at the input of the torque controller.
ru.54 displays the absolute actual position in increments.
Adr.
min max
default
0236h
ru.54 Actual position
1
Inc
-
2147483647
-2147483648
ru.56 displays the absolute set position in increments.
Adr.
min max
default
0238h
ru.56 Set position
1
Inc
-
2147483647
-2147483648
