Functional DescriptionU/f-Characteristic Adjustment
ud.2 0802h ✔ - - 0 11 1 0/4/8 default value dep. on ud.2
uF.0 0500h ✔✔- 0 Hz 400 Hz 0,0125 Hz 50,0 Hz depending on ud.2
uF.1 0501h ✔✔- 0,0 % 25,5 % 0,1 % 2,0 % -
uF.2 0502h ✔✔- -0,0125 Hz 400 Hz 0,0125 Hz 0,0 Hz dep. on ud.2; -0,0125 = parabolic
uF.3 0503h ✔✔- 0,0 % 100,0 % 0,1 % 0,0 % -
uF.4 0504h ✔✔- 0,0 % 25,5 % 0,1 % 0,0 % -
uF.5 0505h ✔✔- 0,00 s 10,00 s 0,01 s 0,00 s -
uF.9 0509h ✔✔- 1 V 649 V; 650: off 1 V 650:off -
uF.10 050Ah ✔✔-0 3 1 0-
uF.11 050Bh ✔✔- 0 PU-Id 1 PU-Id PU-Id: Power unit Identification
uF.19 0513h ✔ -- 0 10 1 0 -
Param. Adr.
min
max
default
ENTER
PROG.
R/W
Step
6.5.8 Used Parameters
small switching frequency
- less inverter heating
- less discharge current
- fewer switching losses
- fewer radio interferences
- improved concentricity at small
speeds
high switching frequency
- less noise development
- improved sine-wave simulation
- less motor losses
Influences and effects of the switching frequency are listed below:
