KEB COMBIVERT F5 MULTI User Manual

3
HardwareControl Cards
3
13
KEB COMBIVERT F5-M / S
Name: Basis
18.05.04
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
3.1.1 Survey
3.1 Control Units
In this application manual the control cards F5-MULTI and F5-SERVO are described.
The control cards have different functional ranges.
3. Hardware
The following section is to get an overview of the F5 control cards.
Contol card MULTI SERVO
Inputs
Set value input ±10 V / 0(4)...20 mA 2 2
Digital inputs (programmable) 8 8
Internal inputs 4 4
External supply of the control card X X
Encoder interface X X
Scan time of the in- and outputs 1 ms 1 ms
Outputs
Analog outputs 2 2
Digital outputs 2 2
Relay outputs 2 2
Internal outputs 4 4
Potential-free operator output X X
Functions
Parameter sets 8 8
Aux function X X
Brake control X X
DC braking X
1)
-
Energy saving function X
1)
-
Speed search X -
Fixed values X X
Electronic motor protection X X
Power on counter X X
Power off function X
2)
X
PI controller X X
Jerk lever starting by s-curves X X
Bus response time 1 ms 1 ms
Suitable for
Housing size >= D X X
1) only for open loop control operation
2) only for closed loop control operation
