KEB COMBIVERT F5 MULTI User Manual

8 1
KEB COMBIVERT F5
8
Name: Basis
10.04.02
Special Operation
Chapter Section Page Date
© KEB Antriebstechnik, 2002
All Rights reserved
8.1.6 Operation Example
Selection of a COMBIVIS parameter list:
An.41 ANOUT 3 Function 12 : Power stage temperature (ru.38)
An.44 ANOUT 3 Offset 30 %
An.43 ANOUT 3 Gain 5,00
An.46 ANOUT 3 Period 20 s
do.06 Switching Condition SB 6 42 : ANOUT3 PWM
do.22 Selection of SB for Flag 6 64 : SB6
do.33 Selection of Flag for O1 64 : M6
An.47 ANOUT 4 Function 13 : Motor Temperature (ru.46)
An.50 ANOUT 4 Offset 40 %
An.49 ANOUT 4 Gain 2,50
An.52 ANOUT 4 Period 20 s
do.07 Switching Condition SB 7 43 : ANOUT4 PWM
do.23 Selection SB for Flag 7 128 : SB7
do.34 Selection of Flag for O2 128 : M7
do.00 Switching Condition SB 0 3: Ready for Operation
do.16 Selection of SB for Flag 0 1: SB0
do.35 Selection of Flag for O2 1: M0
do.01 Selection of SB 1 7: Pre-Warning Overload
do.02 Selection of SB 2 8: Pre-Warning Power Stage Overheat
do.03 Selection of SB 3 9: Pre-Warning Motor Overheat
do.04 Selection of SB 4 11: Warning internal Overheat
do.05 Selection of SB 5 0: alway switched-off
do.17 Selcetion of SB for Flag 1 62: SB1+SB2+SB3+SB4+SB5
do.28 Inverted Flag for R2 2: M1
do.36 Selection of Flag for R2 2: M1
Adjustments of the Temperature
Closed-Loop Control
Adjustments of the Motor-
Temperature Closed-Loop Control
Pre-Warning Adjustments
For future informations please contact KEB.
