KEB COMBIVERT F5
Name: Basis
04.05.04
6
Section PageDate
© KEB Antriebstechnik, 2002
All rights reserved
Chapter
Functional DescriptionSpecial Functions
Source of Setpoint (oP.0) and
Direction of rotation (oP.1)
In order to preset the setpoint by way of the motor potentiometer, oP.0 (setpoint source)
must be set to value „4“. The source of rotation direction (oP.1) must be adjusted in
dependence on the setpoint (value „6“ or „7“).
If the motor potentiometer is used as setpoint source, the setpoint is calculated from
this with the respective limits just as with other percental setpoint sources (see Chapter
6.4. „Set Value Adjustment“).
Motor potentiometer value
(oP.52)
With this parameter a value in percent can be adjusted within the preset limits directly
by operator or bus. The ramp time (oP.59) remains unconsidered at this setting.
Param. Adr.
min
max
default
ENTER
PROG.
RO
Step
Used Parameters
ru.37 0225h - - - -100.00 % 100.00 % 0.01 % - -
oP.0 0300h - ✔✔ 0 9 1 0 „4“ for motor potentiometer
oP.1 0301h - ✔✔ 0 9 1 2 „6 and 7“ rotation direct. over setpoint
oP.50 0332h - - ✔ 0310-
oP.52 0334h - ✔ - -100,00 % 100,00 % 0,01 % 0,00 % -
oP.53 0335h - - - -100,00 % 100,00 % 0,01 % 0,00 % -
oP.54 0336h - - - -100,00 % 100,00 % 0,01 % 100,00 % -
oP.55 0337h - - - -100,00 % 100,00 % 0,01 % 0,00 % -
oP.56 0338h - - ✔ 0 4095 1 0 -
oP.57 0339h - - ✔ 0 4095 1 0 -
oP.58 033Ah - - ✔ 0 4095 1 0 -
oP.59 033Bh - - - 0,00 s 50000,00 s 0,01 s 66,00 s -
