KEB COMBIVERT F5 MULTI User Manual

6
913
KEB COMBIVERT F5
Name: Basis
04.05.04
6
Section PageDate
© KEB Antriebstechnik, 2002
All rights reserved
Chapter
Functional DescriptionSpecial Functions
Param. Adr.
min
max
default
ENTER
PROG.
RO
Step
Comparison level 0...7
(LE.0...LE.7)
LE.0...LE.7 define the level for the switching conditions 37/38 („timer > level“). If the
timer exceeds the adjusted value the switching condition is set. A level in the range of
-10.737.418,24 bis 10.737.418,23 can be adjusted. But only values of 0...655,34 are
sensible for the counter.
Used Parameters
ru.43 022Bh - - - 0,00 655,35 0,01 0,00 -
ru.44 022Ch - - - 0,00 655,35 0,01 0,00 -
LE.0 0D00h - ✔ - -10737418,24 10737418,23 0,01 0 -
LE.1 0D01h - ✔ - -10737418,24 10737418,23 0,01 0 -
LE.2 0D02h - ✔ - -10737418,24 10737418,23 0,01 0 -
LE.3 0D03h - ✔ - -10737418,24 10737418,23 0,01 0 -
LE.4 0D04h - ✔ - -10737418,24 10737418,23 0,01 0 -
LE.5 0D05h - ✔ - -10737418,24 10737418,23 0,01 0 -
LE.6 0D06h - ✔ - -10737418,24 10737418,23 0,01 0 -
LE.7 0D07h - ✔ - -10737418,24 10737418,23 0,01 0 -
LE.17 0D11h - - ✔ 0 4095 1 0 bitcoded
LE.18 0D12h - - ✔ 0710-
LE.19 0D13h - - ✔ 0 4095 1 0 bitcoded
LE.20 0D14h - - ✔ 031116-
LE.21 0D15h - - - 0 31 1 0 -
LE.22 0D16h - - ✔ 0 4095 1 0 bitcoded
LE.23 0D17h - - ✔ 0710-
LE.24 0D18h - - ✔ 0 4095 1 0 bitcoded
LE.25 0D19h - - ✔ 031116-
LE.26 0D1Ah - - - 0 31 1 0 -
Timer Reset condition
(LE.20/25)
According to following table the conditions can be defined under which the timer is
reset in addition to the inputs. The individual conditions are OR-operated.
Bit -No. Decimal value Condition
0 1 Modulation on
1 2 Modulation off
2 4 Setpoint frequency = Actual frequency
3 8 Change of parameter set
4 16 Power-On-Reset
