KEB COMBIVERT F5 MULTI User Manual

2
1
KEB COMBIVERT F5
12
Name: Basis
04.05.04
© KEB Antriebstechnik, 2002
All Rights reserved
Product DescriptionSummary
Chapter Section Page Date
Inverter Size 28 29 30 31
Housing Size W
Phases 3 2 x 3 3 2 x 3 2 x 3 2 x 3
Output nominal power [kVA] 256 319 395 436
Max. rated motor power
8)
[kW] 200 250 315 355
Output nominal current [A] 370 460 570 630
Max. short time current
1)
[A] 463 575 713 787
OC-tripping current [A] 555 690 855 945
Nominal input current [A] 410 2x205 510 2x255 2x315 2x350
Max. permissible mains fuse (inert)
[A] 550 315 700 400 450 550
Rated operating frequency [kHz] 2 2 2 2
Max. operating frequency [kHz] 4 2 2 2
Power loss at nominal operating [W] 3500 4200 5100 5600
Stall current at 4kHz
3)
[A] 370 ñ ñ
Max. heat sink temperature TOH [∞C] 90 90 90 60
Motor line cross section
4)
[mm≤] 2x95 2x150 2x185 2x185
Min. brakin
g
resistor
5)
[Ohm] 1,2 1,2 1,2 1,2
Typ. braking resistor
5)
[Ohm] 2,2 1,7 1,3 ñ
Max. braking current [A] 660 660 660 660
Overload curve 2
Tightening torque for terminals [Nm] 25...30
Mains voltage
6)
[V] 305...500 ±0
Mains frequency [Hz] 50 / 60 +/- 2
Output voltage [V] 3 x 0...U mains
Output frequency [Hz] see control card
Max. shielded motor line length [m] 50
Storage temperature [∞C] -25...70 ∞C
Operating temperature [∞C] -10...45 ∞C
-10...45 ∞C
7)
Model / protective system IP20
Relative humidity max. 95% without condensation
EMC tested in accordance with ... EN 61800-3
Climatic category 3K3 according EN 50178
1) With the regulated systems F5-M as well as F5-S 5% are to be subtracted as control reserve.
2) Fuses of type Ferraz Shawmut 6,6 UD Type 31
3) Max. current before the responding of the OL2-function (only F5-M; F5-S; F5-A)
4) Recommended minimum cross section for rated power and a cable length of upto 100m (copper)
5) This data is only valid for units with internal brake transistor (see "unit identification")
6) Rated voltage 400V; at mains voltage ≥ 460V multiply the rated current with factor 0.86.
7) The temperature range is only valid for the control circuit. For the power circuit the temperature range is depending on
the control cabinet installation and the cooling system.
8) 31.F5 only watercooled.
