KEB COMBIVERT F5 MULTI User Manual

6
933
KEB COMBIVERT F5
Name: Basis
04.05.04
6
Section PageDate
© KEB Antriebstechnik, 2002
All rights reserved
Chapter
Functional DescriptionSpecial Functions
The drive runs with different speed back and forth and always reverses at the same
points.
Downloadlist:
Set Parameter Value Notes
0 Ud01 Password 440
0 Fr01 Copy parameter set -2: def. cust.para all sets
0-3 oP00 Reference source 0: Analog REF
0-3 oP01 Rotation source 0: dig.(op.2), 0-lim.
0 oP02 Rotation setting 1: forward Set 0: clockwise rotation
1 oP02 Rotation setting 0: low speed Set 1: clockwise rotation positioning
2 oP02 Rotation setting 2: reverse Set 2: counterclockwise rotation
3 oP02 Rotation setting 0: low speed Set 3: counterclockwise positioning
0-3 oP10 Max. reference forward 70,0000 Hz The max. setpoint value must be the
same in all sets.
0-3 oP11 Max. reference reverse -1: = see oP.10 The max. setpoint value can be different
for the direction of rotation.
0-3 oP28 Acc. time forward 0,10 s
0-3 oP30 Dec. time forward 0,10 s
0 Pn63 Positioning delay -1: off
1 Pn63 Positioning delay 0,8 s Shifting of the position at clockwise
rotation
2 Pn63 Positioning delay -1: off
3 Pn63 Positioning delay 3,1 s Shifting the position at counterclockwise
rotation
0 Fr02 Parameter set source 2: terminal binary coded
0 Fr05 Set activation delay 0,00 s Additional break between counter-
clockwise and clockwise rotation
1 Fr05 Set activation delay 0,00 s This time must be = 0
2 Fr05 Set activation delay 0,00 s Additional break between clockwise and
counterclockwise rotation
3 Fr05 Set activation delay 0,00 s This time must be = 0
0 Fr06 Set deactivation delay 0,00 s This time must be = 0
1 Fr06 Set deactivation delay 1,00 s Break between clockwise and
counterclockwise rotation
2 Fr06 Set deactivation delay 0,00 s This time must be = 0
3 Fr06 Set deactivation delay 1,00 s Break between counterclockwise and
clockwise rotation
0 Fr07 Para. set input selection 272: I1+IA
0 Fr11 Reset set input selection 0: no input
0 di11 I1 Function 2048: Set sel. Initiator signal
0 di15 IA Function 2048: Set sel. Changeover between clockwise and
counterclockwise rotation
0 do04 Condition 1 0: off Initiator active: -> set 1
1 do04 Condition 1 1: on Positioning completed: -> set 2
2 do04 Condition 1 1: on Initiator active: -> set 3
3 do04 Condition 1 0: off Positioning completed: -> set 0
Exsample 2
