KEB COMBIVERT F5 MULTI User Manual

7
9
17
KEB COMBIVERT F5
Name: Basis
04.05.04
9
Error Assistance
Section PageDate
© KEB Antriebstechnik, 2002
All Rights reserved
Chapter
E.PrF ERROR prot. rot. for. 46 The drive has driven onto the right limit switch. Programmed
response “Error, restart after reset” (see chapter 6.7
“Response to errors or warning messages”).
E.Prr ERROR prot. rot. rev. 47 The drive has driven onto the left limit switch. Programmed
response “Error, restart after reset” (see chapter 6.7
“Response to errors or warning messages”).
E. Pu ERROR power unit 12 Error: General power circuit fault
E.Puci ERROR pow. unit code inv. 49 Error: During the initialization the power circuit could not be
recognized or was identified as invalid.
E.Puch ERROR power unit changed 50 Error: Power circuit identification was changed; with a valid
power circuit this error can be reset by writing to SY.3. If the
value displayed in SY.3 is written, only the power-circuit
dependent parameters are reinitialized. If any other value is
written, then the default set is loaded. On some systems
after writing Sy.3 a Power-On-Reset is necessary.
E.PUCO ERROR power unit commun. 22 Error: Parameter value could not be written to the power
circuit. Acknowledgement from PC <> OK
E.PUIN ERROR power unit invalid 14 Error: Software version for power circuit and control card are
different. Error cannot be reset (only at F5-G B-housing)
E.SbuS ERROR bus synchron 23 Sychronization over sercos-bus not possible. Programmed
response “Error, restart after reset” (see chapter 6.7
“Response to errors or warning messages”).
E.SEt ERROR set 39 It has been attempted to select a locked parameter set.
Programmed response “Error, restart after reset” (see chapter
6.7 “Response to errors or warning messages”).
E.SLF ERROR! Software limit switch forward 44 The target position lies outside of the limit defined with the
right software limit switch.Programmed response “Error,
restart after reset” (see chapter 6.7 “Response to errors or
warning messages”).
E.SLr ERROR software limit switch reverse 45 The target position lies outside of the limit defined with the
left software limit switch. Programmed response “Error,
restart after reset” (see chapter 6.7 “Response to errors or
warning messages”).
E. UP ERROR underpotential 2 Error: Undervoltage (DC-link circuit). Occurs, if DC-link
voltage falls below the permissible value. Causes:
• input voltage too low or instable
• inverter rating too small
• voltage losses through wrong cabling
• the supply voltage through generator / transformer breaks
down at very short ramps
• At F5-G housing B E.UP is also displayed if no
communication takes place between power circuit and control
card.
• Jump factor (Pn.56) too small (see 6.9.20)
• if a digital input was programmed as external error input
with error message E.UP (Pn.65).
E.UPh ERROR Phase failure 3 One phase of the input voltage is missing (ripple-detection)
Warning Messages
Display COMBIVIS Value Meaning
