Functional Desription Operating and Unit Data
Adr.
min max
default
0E19h
1
-
0
655350
Shows the 8 errors (in the sets 0...7) that occurred last. The oldest error is in set 7. Between errors of the same type a
differential time is determined and stored too.
Bit 0...11 Value 0...4094 differential ime in minutes
Value 4095 differential time > 4094 minutes
Bit 12...15 Value Error type Value Error type Value Error type
0 no erors 3 E.OP 6...15 free
1 E.OC 4 E.OH
2 E.OL 5 E.OHI
In.25 Error diagnosis
Adr.
min max
default
1
-
0
655350
In.26 E.OC error counter 0E1Ah
In.27 E.OL error counter 0E1Bh
In.28 E.OP error counter 0E1Ch
In.29 E.OH error counter 0E1Dh
In.30 E.OHI error counter 0E1Eh
The error counters (for E.OC, E.OL, E.OP, E.OH, E.OHI) state the total number of the different error types that occurred.
s.o.
Adr.
min max
default
0E1Fh
1
-
-
655350
In.31 shows the version of the KEB - Hiperface.
In.31 KEB - Hiperface
Adr.
min max
default
0E20h
1
-
-
655350
In.32 shows the date of the interface software.
In.32 Interface Softwaredatum
