Functional Description CP-Parameter Definition
6.13.4 Display
Standardization
The KEB COMBIVERT gives the user the possibility to define his own standardization
(e.g. km/h or bottles/min) in the CP-Mode. The parameters ud.18...20 are used for
conversion, ud.21 for specifying the method of calculation, the decimal places as well
as the units indicated in KEB COMBIVIS.
6.12.4 Definition of own standardization
ud.19 Multiplier
± 32767
ud.20 Offset
± 32767
ud.18 Divisor
± 32767
ud.21 Display flags
0...4095
CP.xx = (selected parameter + ud.20) x
ud.19
x Unit
ud.18
ud.19 Multiplier
± 32767
ud.20 Offset
± 32767
ud.18 Divisor
± 32767
CP.xx =
ud.19
x Unit
(selected parameter + ud.20) x ud.18
ud.18 Display standardization
Divisor
Adjusts the divisor in the range of ±32767 (default 1). The parameter is set-
programmable (not at B-control).
ud.19 Display standardization
Multiplier
Adjusts the multiplier in the range of ±32767 (default 1). The parameter is set-
programmable (not at B-control).
ud.20 Display standardization
Offset
Adjusts the offset in the range of ±32767 (default 0). The parameter is set-programmable
(not at B-control).
ud.21 Display standardization
Mode
With ud.21 the calculation mode, the decimal places as well as the units indicated in
KEB COMBIVIS are adjusted. The parameter is bit-coded and set-programmable (not
at B-control). It is adjustable in the range of 0...4095.
Bit 12...15 Bit 11...8 Bit 7...6 Bit 5...0 ud.21
- - - see table 1 Unit
- - see table 2 - Calculation mode
- see table 3 - - Representation
free - - - -
Standard
Inverted
The unstandardized value is always used for the „selected parameter“ !
