KEB COMBIVERT F5 Servo User Manual

CP - ParameterOperation
4
3
KEB COMBIVERT F5-M / S22
Name: Basis
17.05.04
Chapter Section Page Date
© KEB Antriebstechnik, 2003
All Rights reserved
4.3.7 Factory Settings
In the table below the factory settings for the size-dependent parameter values are
listed.
Housing CP.11 CP.12 CP.13 CP.14 CP.15 CP.16 CP.29
size [rpm] [Hz] [A] [V] cos Phi [kW] [Nm] [Nm]
Rated motor Rated motor Rated motor Rated motor Rated motor Rated motor Rated motor Maximum
speed frequency current voltage cos (Phi) power torque torque
09/200V 1400 50 5,9 230 0,83 1,5 10,23 22,09
10/200V 1420 50 9,0 230 0,78 2,2 14,79 30,68
12/200V 1435 50 15,2 230 0,79 4,0 26,61 53,53
13/200V 1440 50 18,2 230 0,89 5,5 36,47 69,92
14/200V 1450 50 26,0 230 0,84 7,5 49,39 93,40
15/200V 1450 50 37,5 230 0,85 11,0 72,43 137,48
16/200V 1465 50 50,0 230 0,86 15,0 97,76 190,64
17/200V 1460 50 60,5 230 0,86 18,5 120,99 248,74
09/400V 1400 50 3,4 400 0,83 1,5 10,23 22,47
10/400V 1420 50 5,2 400 0,78 2,2 14,79 30,81
12/400V 1435 50 8,8 400 0,79 4,0 26,61 53,21
13/400V 1440 50 10,5 400 0,89 5,5 36,47 73,26
14/400V 1450 50 15,0 400 0,84 7,5 49,39 80,12
15/400V 1450 50 21,5 400 0,85 11,0 72,43 118,83
16/400V 1465 50 28,5 400 0,86 15,0 97,76 165,88
17/400V 1460 50 35,0 400 0,86 18,5 120,99 213,37
18/400V 1465 50 42,0 400 0,84 22,0 143,83 253,27
19/400V 1465 50 55,5 400 0,85 30,0 195,52 309,88
20/400V 1470 50 67,0 400 0,86 37,0 240,33 393,60
21/400V 1470 50 81,0 400 0,86 45,0 292,29 474,91
22/400V 1475 50 98,5 400 0,86 55,0 356,03 609,86
23/400V 1480 50 140,0 400 0,87 75,0 483,85 752,75
24/400V 1480 50 168,0 400 0,86 90,0 580,63 907,29
25/400V 1485 50 210,0 400 0,85 110,0 707,26 833,38
26/400V 1485 50 240,0 400 0,87 132,0 848,72 1.041,70
27/400V 1485 50 287,0 400 0,88 160,0 1028,75 1.264,01
28/400V 1485 50 370,0 400 0,88 200,0 1285,93 1.413,37
29/400V 1485 50 420,0 400 0,88 250,0 1607,42 1.780,29
30/400V 1490 50 535,0 400 0,88 315,0 2018,55 1.938,63
31/400V 1490 50 623,0 400 0,85 355,0 2274,87 2.566,84
32/400V 1490 50 710,0 400 0,84 400,0 2563,24 3.012,88
F5-MULTI:
