Reaction to limit switch
Adjustment range: 0...6
Resolution: 1
Factory setting: 6
Adjustment range: 0...6
Resolution: 1
Factory setting: 0
With the external error monitoring external units can take direct influence on the drive.
This parameter determines the response of the drive to a signal at terminal X2A.12
(I3) according to following table.
This parameter determines the reaction of the drive, to terminal X2A.14 (F) and/or
X2A.15 (R). These terminals are programmed as limit switches. The reaction of the
drive is shown in the table below.
Reaction to external fault
CP.35 Display Reaction Restart
0 E.PRx Immediate disabling of modulation
1 A.PRx Quick stopping / disabling of
modulation after reaching speed 0
2 A.PRx Quick stopping/holding toruqe at speed 0
3 A.PRx Immediate disabling of modulation
4 A.PRx Quick stopping / disabling of
modulation after reaching speed 0
5 A.PRx Quick stopping/holding toruqe at speed 0
6noNo effect on the drive;
! Fault is ignored !
Remove fault;
Actuate reset
Automatic reset,
if the fault is no
longer
present
- inapplicable -
CP.36 Display Reaction Restart
0 E. EF Immediate disabling of modulation
1 A. EF Quick stopping / disabling of
modulation after reaching speed 0
2 A. EF Quick stopping/holding toruqe at speed 0
3 A. EF Immediate disabling of modulation
4 A. EF Quick stopping / disabling of
modulation after reaching speed 0
5 A. EF Quick stopping/holding toruqe at speed 0
6noNo effect on the drive;
! Fault is ignored !
Remove fault;
Actuate reset
Automatic reset,
if the fault is no
longer
present
- inapplicable -
Factory setting CP.33: 4
Factory setting CP.34: 2
Note: Enter-Parameter
