KEB COMBIVERT F5 Servo

4
CP - Parameter Operation
4
323
KEB COMBIVERT F5-M / S
Name: Basis
17.05.04
Section PageDate
© KEB Antriebstechnik, 2003
All Rights reserved
Chapter
The following table contains the motor data of standard motors.
F5-SERVO:
Rated torque [Nm] Rated speed [rpm] Rated frequency [Hz] Rated current [A] Back-EMF constant [V / 1000 rpm] Winding inductance [mH] Windin
g
resistance
Housing size Default Motor CP.11 CP.12 CP.13 CP.14 CP.15 CP.16 C
P
09/200V C3.SM.000-3200 3,9 3000 150 4,20 69 6,90 2
,
10/200V C4.SM.000-3200 5,0 3000 150 5,70 68 4,50 1
,
12/200V D2.SM.000-3200 6,1 3000 150 8,10 67 4,00 1
,
13/200V D3.SM.000-3200 8,4 3000 150 10,90 69 2,80 0
,
14/200V E4.SM.000-3200 15,5 3000 150 16,00 89 1,30 0
,
09/400V C3.SM.000-3400 3,9 3000 150 2,40 118 20,60 5
,
10/400V C4.SM.000-3400 5,0 3000 150 3,40 113 13,10 3
,
12/400V D2.SM.000-3400 6,1 3000 150 4,50 119 12,80 3
,
13/400V D4.SM.000.3400 9,9 3000 150 7,30 121 1,50 1
,
14/400V E2.SM.000-3400 11,0 3000 150 7,00 136 8,20 2
,
15/400V E4.SM.000-3400 15,5 3000 150 9,90 143 3,40 0
,
16/400V F1.SM.000-3400 20,0 3000 150 13,80 130 7,00 0
,
17/400V F2.SM.000-3400 31,0 3000 150 20,60 135 3,60 0
,
18/400V F3.SM.000-3400 3,3 3000 150 22,90 131 1,70 0
,
