Functional DescriptionCP-Parameter Definition
Table 1 Unit
Value Unit Value Unit Value Unit Value Unit
0 none 16 km/h 32 K 48 lbin
1 mm 17 1/min 33 mΩ 49 in/s
2cm 18Hz 34Ω 50 ft/s
3 m 19 kHz 35 k Ω 51 ft/min
4 km 20 mV 36 INC 52 ft/s²
5 g 21 V 37 % 53 ft/s³
6kg 22kV 38KWh 54MPH
7us 23mW 39mH 55kp
8ms 24W 40- 56psi
9 s 25 kW 41 - 57 °F
10h 26VA 42in 58-
11Nm 27kVA 43ft 59-
12 kNm 28 mA 44 yd 60 -
13 m/s 29 A 45 oz 61 -
14 m/s
2
30 kA 46 lb 62 -
15 m/s
3
31 °C 47 lbft 63 -
Table 2
Calculation mode
(selected parameter + ud.20) x
ud.19
= CP.xx
ud.18
ud.19
= CP.xx
(selected parameter + ud.20) x ud.18
Value
0
64
-
-
free
free
Function
Value Representation
0 0 decimal places
256 1 demical place
512 2 decimal places
768 3 decimal places
1024 4 decimal places
1280 variable decimal places
1536 Hexadecimal
- free
Table 3
Representation
Example
The actual frequency shall be displayed in CP.1 in rpm. Display standardization from
set 4.
ud.15 = 1 ; CP.1
ud.16 = 0203h ; Actual frequency ru.3
ud.17 = 4352 ; Display in current set, display standardization from set 4
Satz 4 ud.18 = 80
; Conversion from 1/80 Hz into rpm without pole pair number
Satz 4 ud.19 = 60
Satz 4 ud.20 = 0 ; no Offset
Satz 4 ud.21 = 17 ; Unit rpm; direct calculation mode; no decimal places
The
unstandardized
value is always
used for the
„selected
parameter“ !
