2.1.4 Type Code
10.F5.G1Bñ3200
at FI: Cooling at Servos: motor cooling
0: Standard 0: Self-cooling
1: Flat rear 1: External cooling
2: Water-cooled
3: Convection
Encoder interface type see control part
0: no interface 5: Resolver a. SSI A: Ink.-Input a. Initiator F: Hiperface a. Ink.-Outp.
1: Ink.-Input a. Ink.-I/O 6: Hiperface a. SSI B: Resolver a. Initiator G: Ink.-Input a. Ink.-Inp.
2: Resolver a. Ink.-I/O 7: Ink.-Input a. Tacho C: Hiperface a. Initiator H: Resolver a. Ink.-Inp.
3: Hiperface a. Ink.-I/O 8: Resolver a. Tacho D: Ink.-Input a. Ink.-Outp. I: Hiperface a. Ink.-Inp.
4: Ink.-Input a. SSI 9: Hiperface a. Tacho E: Resolver a. Ink.-Outp.
at FI: Switching frequency / max. short time current / OC-tripping current
0: 2 kHz/125%/150% 5: 4 kHz/150%/180% A: 8 kHz/180%/216% F: 16 kHz/200%/240%
1: 4 kHz/125%/150% 6: 8 kHz/150%/180% B: 16 kHz/180%/216% G: 2 kHz/400%/480%
2: 8 kHz/125%/150% 7: 16 kHz/150%/180% C: 2 kHz/200%/240% H: 4 kHz/400%/480%
3: 16 kHz/125%/150% 8: 2 kHz/180%/216% D: 4 kHz/200%/240% I: 8 kHz/400%/480%
4: 2 kHz/150%/180% 9: 4 kHz/180%/216% E: 8 kHz/200%/240% K: 16 kHz/400%/480%
at Servos: motor speed
1: 1500 rpm 2: 2000 rpm 3: 3000 rpm 4: 4000 rpm 6: 6000 rpm
Input identification
0: 1ph 230V AC/DC 5: 400V DC A: 6ph 400V AC
1: 3ph 230V AC/DC 6: 1ph 230V AC Z: 230V AC or AC/DC
2: 1/3ph 230V AC/DC 7: 3ph 230V AC Y: 400V AC or AC/DC
3: 3ph 400V AC/DC 8: 1/3ph 230V AC W: 230V DC
4: 230V DC 9: 3ph 400V AC V: 400V DC
Housing type A, B, D, E, G, H, R, U, W
Accessory
0: without 4: integrated PFC
2)
1: GTR 7
1)
5: GTR 7
1)
, integrated PFC
2)
2: integrated filter 6: integrated filter , integrated PFC
2)
3: GTR 7
1)
, integrated filter 7: GTR 7
1)
, integrated filter, integrated PFC
2)
Control type
B: BASIC (controlled frequency inverter with standard function)
G: GENERAL (controlled frequency inverter with enhanced function)
C: COMPACT (controlled frequency inverter with enhanced function)
M: MULTI (regulated, field-oriented frequency inverter for three-phase asynchronous motors)
S: SERVO (regulated frequency inverter for synchronous motors)
Series F5
at FI in the 1. and 2. place: unit size
at Servos: motor identification / motor dimension wide
1) GTR 7: brake transistor
2) PFC: Power Factor Control
