6 7

KEB COMBIVERT F5

Name: Basis

04.05.04

Chapter Section Page Date

Functional Description Protective Functions

Pn.3 0403h ✔ -- 0 6 1 0 -

Pn.4 0404h ✔ - ✔ 0 4095 1 64 64 => I3

Pn.5 0405h ✔ -- 0 6 1 6 -

Pn.6 0406h ✔ - - 0: oFF 10,00 s 0,01 s 0: oFF -

Pn.7 0407h ✔ -- 0 6 1 6 -

Pn.8 0408h ✔ -- 0 6 1 6 -

Pn.9 0409h ✔ - - 0 % 100 % 1 % 80 % -

Pn.10 040Ah ✔ -- 0 6 1 6 -

Pn.11 040Bh ✔ - - 0 °C 90 °C 1 °C 70 °C -

Pn.12 040Ch ✔ -- 0 7 1 6 -

Pn.13 040Dh ✔ - - 0 120 s 1 s 10 s -

Pn.14 040Eh ✔ -- 0 6 1 6 -

Pn.15 040Fh ✔ - - 0 % 100 % 1 % 100 % only for F5-S

Pn.16 0410h ✔ -- 0 7 1 7 -

Pn.17 0411h ✔ - - 0 s 120 s 1 s 0 s -

Pn.18 0412h ✔ -- 0 6 1 0 -

Pn.58 043Ah ✔ - ✔ 0 3 1 0 only for F5-G

Pn.59 043bh ✔ - - 0 % 200 % 1 % 200 % only for F5-G

Pn.60 043Ch ✔ - - 0,00 s 300,00 s 0,01 s 2,00 s -

Pn.61 043Dh ✔ - - 0,00 Nm 10000,00 Nm 0,01 Nm Adaption -

Pn.62 043Eh ✔ - - 0 °C 200 °C 1 °C 100 °C -

Pn.66 0442h ✔ -- 0 6 1 6 -

Pn.67 0443h ✔✔- 0 Nm 10000,00 Nm 0,01 Nm Adapt. -

Pn.68 0444h ✔ - - 0,00 s 100,00 s 0,01 s 0,00 s -

Param. Adr.

min

max

default

ENTER

PROG.

R/W

Step

Used Parameters

Function description F5-M/S

At quick stop the motor is decelerated with the adjusted ramp time (pn.60) with LD(U)-

Stop or at the torque limit (pn.61) to 0 rpm .

In case of abnormal stopping with holding torque the modulation remains active,

otherwise it is switched off (also at quick stop via control word sy. 50 bit 8).
