KEB COMBIVERT F5 Servo User Manual

6 9
KEB COMBIVERT F5
32
Name: Basis
04.05.04
Chapter Section Page Date
© KEB Antriebstechnik, 2002
All rights reserved
Functional Description Special Functions
Exsample 1 The drive runs a distance, positions and remains at the stop position for a time. The
new cycle starts.
Download list:
Set Parameter Value Notes
0 Ud01 Password 440
0 Fr01 Copy parameter set -2: def. cust.para all sets
0-1 oP00 Reference source 0: Analog REF
0 oP01 Rotation source 2: F/R, 0-lim. Set 0: running
1 oP01 Rotation source 0: dig., 0-lim. Set 1: positioning
1 oP02 Rotation setting 0: low speed
0-1 oP10 Max. reference forward 70,0000 Hz The max. setpoint value must be the
same in all sets.
0-1 oP28 Acc. time forward 0,01 s
0-1 oP30 Dec. time forward 0,20 s
0 Pn63 Positioning delay -1: off
1 Pn63 Positioning delay 5,00 s Shifting of the stop position
0 Fr02 Parameter set source 3: term. inp. coded ST-I1-ID
0 Fr05 Set activation delay 1,00 s Additonal break at the stop position
1 Fr05 Set activation delay 0,00 s This time must be = 0
0 Fr06 Set deactivation delay 0,00 s This time must be = 0
1 Fr06 Set deactivation delay 2,55 s Break at the stop position
0 Fr07 Para. set input selection 16: I1
0 di11 I1 Function 2048: Set selection initiator signal
