6.12 FTP mode
Inverter parameter
Operator parameter
Parameter saving
Up/Download
Work list
File operations
FTP mode
Enter test mode
ENTER opens the submenu for the FTP mode.
The FTP mode is used to transfer files from/in the flash file
system via the KebFTP protocol. For the Ethernet operator, the
FTP mode is always available via UDP port 8002. For the USB
operator, the USB interface is changed in this mode for KebFTP
operation and does not longer respond to DIN66019II requests.
The used baud rate is freely selectable for USB.
Figure 22: FTP mode
One of the programs ‘KEB FTP’ or ‘COMBIVIS’ is required to install missing les. Each
le can be protected with an access level ( File operations).
6.13 Function test of keyboard and display
Inverter parameter
Operator parameter
Parameter saving
Up/Download
Work list
File operations
FTP mode
Enter test mode
ENTER starts a test mode, to check the function of the single
keys and the LC-display.
Follow the instructions on the display during the test run.
Figure 23: Function test of keyboard and display
39
